For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues so that they can then be wiped off much more easily
This device is a version intended for the European market and is not a re-import device with Swiss connection and equipment specifications.
Equipment
- Device type: wall extractor hood
- Width: 90 cm
- Design: mirror glass
- Exhaust air mode, recirculation mode with accessories
Features
- Premium Swiss Quality Developing and producing innovative, high-quality products at the highest possible technological level is a tradition in Switzerland. The family business V-ZUG AG, founded in 1913, has repeatedly succeeded in making a name for itself in the industry. It is known for regularly developing and bringing world firsts to market. With these milestones, V-ZUG continues to set a sustainable and noble example in the industry.
- Telescopic casing
- Intensive level
- Automatic overrun
- Remote control optional
- LED lighting
- Grease filter: 3
- Backflow flap included
Operation & displays
- Touch Control
- Sensor buttons
- Fan level display
- Number of lighting: 2
- V-ZUG grease filter
The exclusive program for the ideal cleaning of extractor hood grease filters. The rinsing process is designed in such a way that the various layers of aluminum knitted metal inside the grease filters are cleaned gently but still very effectively. This guarantees a long service life for the grease filters!
cleaning indicatorAfter 15 hours of operation or at the latest 14 days after
the indicator lights up for the first time. The saturation level has been reached and the grease filter needs to be cleaned. With optimal care
the service life of a grease filter is almost unlimited.
- V-ZUG ComfortFix
For easy and safe removal of the magnetically attached grease filters
- V-ZUG OptiLink
extractor hood regulates itself automatically in exchange with the hob
Energy values
- Energy efficiency class: A+
- Annual energy consumption: 28.2 kWh
- Lighting efficiency class: A
- Fluid dynamic efficiency: 36.3
- Fluid dynamic efficiency class: A
- Rated voltage (1): 220-240 V~
- Rated lighting power (number x W): 2 x 2 W
- Frequency (1): 50/60 Hz
- Rated power (1): 0.13 kW
- Fuse value (1): 10.0 A
- Plug type: Schuko 16A
- Connection cable: 1.2 m
Further data
- Sound power circulating air max. level: 56 dB(A)
- Light color in Kelvin: 2700 K
- Light color in Kelvin upper value: 4000 K
- Exhaust air connection diameter: 150 mm
- Lighting efficiency: 28
- Illuminance on the cooking surface: 113 lux
- Class for the degree of fat separation: B
- Air output exhaust air intensive level: 675 m³/h
- Air output exhaust air max. level: 452 m³/h
- Air output exhaust air min. level: 247 m³/h
- Air output circulating air intensive level: 570 m³/h
- Air output circulating air max. level: 389 m³/h
- Air output circulating air min. level: 210 m³/h
- Sound power exhaust air intensive level: 63 dB(A)
- Noise level exhaust air max. level: 52 dB(A)
- Sound power exhaust air min. level: 38 dB(A)
- Sound power circulating air intensive level: 68 dB(A)
- Connection for supply/exhaust air flap: Yes
- Number of motors: 1
- Rated motor power: 130.0 W
Dimensions
- Device height exhaust air 460.0 mm
- Device height of exhaust air maximum 660.0 mm
- Device height for circulating air 570.0 mm
- Device height for circulating air maximum 770.0 mm
- Front height 55.0 mm
- Device width 898.0 mm
- Device depth 550.0 mm
- Device depth max. 550.0 mm
- Empty weight 25.5 kg
* Information about the manufacturer's warranty
The manufacturer offers a 10-year guarantee on the delivered item throughout Germany. If material or manufacturing defects occur during this period, the manufacturer will provide one of the following services at its discretion under the guarantee:
V-ZUG Europe BV
Eevee 102
8530 Harelbeke-Kortrijk
BELGIUM
Service hotline: 00800 850 850 00
Note:
Your statutory warranty rights towards us remain unaffected. If the purchased item is defective, you can contact us in any case, regardless of whether the warranty case occurs and whether the warranty is claimed or not.
