Neff D98IPT2Y5, N90 wall panel, 90 cm, with Flex Design, brushed bronze Z91BIE9BY0, 7 YEAR WARRANTY*
Neff Collection - Top accents in kitchen design
- Flex Design: change the style of your kitchen according to your taste. At any time.
- Efficient Drive motor technology: Quiet and energy-efficient hood motor for more peace and quiet in the kitchen.
- Automatic air sensor – automatically adjusts the trigger strength
- Hob-based hood control: Extractor strength and lighting as required.
- LED color temperature: Warm or cold light? Adjust the lighting on your extractor hood to suit your mood.
Design
- Flex Design including design kit Brushed Bronze Z91BIE9BY0
- additional design kits can be retrofitted (see accessories)
- Slanted Food Design
- Wall mounting
- Glass pane: black printed
- Optional exhaust air or recirculation mode
- Chimney-free operation possible with recirculated air
- The Clean Air Plus recirculation set (accessory) or the Longlife recirculation set (accessory) is required for recirculation operation.
Most important features
- Efficient Drive motor technology - quiet and energy-efficient motor
- Lighting: 2 pieces, LED, 3 W, with color temperature adjustable
- Softlight: the lighting switches on and off gently.
- Dimming function: the brightness of the lighting can be adjusted.
- Color temperature: 3500 K
- Illuminance: 422 lux
- Boost Position: Intermediate positions of the glass filter cover to better extract particularly strong cooking odors and amounts of steam.
- Extractor hood on the front and bottom
- 3 metal grease filters
Comfort
- Air quality sensor Automatic Air: Automatic sensor-based performance control for best results
- Touch Control
- 3 performance levels and 2 intensive levels
- Automatic reset from intensive to normal level after 6 minutes
- Saturation display for grease and odor filters
- Automatic run-on time: 10 minutes
- Extremely large opening angle for easy access to the filters and easy cleaning.
- The surfaces and materials are smooth and easy to clean.
- Aerodynamically optimized inner frame, easy to clean
- Metal grease filter, dishwasher safe
Output exhaust air
- According to EN 61591 and EN/IEC 60704-2-13, your device can achieve the following values in exhaust mode:
- Performance level 1: Fan performance: 228 m3/h; Noise value: 35 dB(A) re1pW
- Performance level 2: Fan performance: 325 m3/h; Noise value: 43 dB(A) re1pW
- Performance level 3: Fan performance: 41 m3/h; Noise value: 51 dB(A) re1pW
- Intensive level 1: Fan performance: 753 m3/h; Noise value: 65 dB(A) re1pW
- Intensive level 2: Fan performance: 1007 m3/h; Noise value: 70 dB (A) re1pW
- Energy efficiency class: A+ (on an energy efficiency class scale from A+++ to D)
- Average energy consumption: 39.1 kWh/year
- Fan efficiency class: A
- Lighting efficiency class: A
- Grease filter efficiency class: C
Recirculation air performance
- According to EN 61591 and EN/IEC 60704-2-13, your device can achieve the following values in recirculation mode with the Clean Air plus recirculation set for installation with a chimney:
- Performance level 1: Fan performance: 211 m3/h; Noise value: 42 dB(A) re1pW
- Performance level 2: Fan performance: 315 m3/h; Noise value: 51 dB(A) re1pW
- Performance level 3: Fan performance: 435 m3/h; Noise value: 59 dB(A) re1pW
- Intensive level 1: Fan performance: 752 m3/h; Noise value: 72 dB(A) re1pW
- Intensive level 2: Fan performance: 964 m3/h; Noise value: 78 dB (A) re1pW
- According to EN 61591 and EN/IEC 60704-2-13, your device can achieve the following values in recirculation mode with the Clean Air plus recirculation set for chimney-free installation:
- Performance level 1: Fan performance: 214 m3/h; Noise value: 42 dB(A) re1pW
- Performance level 2: Fan performance: 312 m3/h; Noise value: 51 dB(A) re1pW
- Performance level 3: Fan performance: 437 m3/h; Noise value: 60 dB(A) re1pW
- Intensive level 1: Fan performance: 751 m3/h; Noise value: 74 dB(A) re1pW
- Intensive level 2: Fan performance: 944 m3/h; Noise value: 80 dB (A) re1pW
Technical data and sustainability
- Total connected load: 250 W
- Voltage: 220 - 240 V
- Made in Germany: manufactured in a CO2-neutral production facility
- Environmentally friendly packaging
- The most efficient fan technology on the market
- Available odor filter as a regenerable long life filter with a service life of 10 years
- Air quality sensor Automatic Air: Sensor-based performance control for best results with minimal energy consumption.
Planning and installation
- Device dimensions, exhaust air (HxWxD): 855-1098 x 890 x 447 mm
- Device dimensions for circulating air (HxWxD): 892-1185 x 890 x 447 mm
- Dimensions of recirculating air installation, chimneyless (HxWxD): 471 mm x 890 mm x 447 mm
- Simple and weight-reduced installation thanks to the new Easy Installation System
- Exhaust air connection Ø 150 mm
- Length of connection cable: 1.3 m with plug
- Delivery with backflow flap
