For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking chamber and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

Design

• Tempered glass surface, black
• Two installation options: install the hob either flush or lying on the worktop
• Semi-continuous cast iron pan supports
• Illuminated stainless steel rotary selector

Burner and Performance

• 5 gas burners

• Includes 1 dual wok burner: Use a particularly wide power range and control two flame rings separately.

• Left: Wok burner up to 5 kW (depending on the type of gas)

• Front center: Normal burner up to 1.75 kW (depending on the type of gas)

• Rear center: Economy burner up to 1.75 kW (depending on the type of gas)

• Rear right: Power burner up to 3 kW (depending on the type of gas)

• Front right: normal burner up to 1 kW (depending on the type of gas)

Ease of use

• stepFlame technology - power control in 9 levels: Adjust the flame precisely in nine defined levels.

• Digital function display: shows the selected power level and residual heat.
• Control knob, front: easily accessible and operable knobs in the front area for effortless turning.
• One-handed ignition: To ignite the flame, simply press and turn the knob.
• Timer: an alarm sounds at the end of the set time (e.g. for pasta).

Cleaning

• Removable sword toggles: simplifies cleaning between toggles.

• Dishwasher-safe pot supports: easy to clean in the dishwasher.

• Semi-continuous cast iron pot supports: low weight and compact shape with high stability thanks to the continuous surface.

Security

• Ignition safety device: prevents further gas flow when the flame goes out.

• 5-fold residual heat indicator: shows which burner parts and pan supports are still hot.

Networking

• Home Connect: check whether the hob is switched off while on the move and use many other functions in the Home Connect app.
• cookConnect system (with matching extractor hood): automatically activates the extractor hood while cooking, thanks to the WiFi connection between the hob and extractor hood.
• Intelligent automatic extractor hood: the extractor hood automatically adjusts the fan power to the hob settings (with a suitable extractor hood and a connected Home Connect account).
• The volume of the Touch Control can be adjusted in the Home Connect app depending on your preference.

Installation (gas types & measurements)

• Can be used for: Natural gas L/LL G25/20 mbar (DE)

• Natural gas H/E 20 mbar, E+ 20/25 mbar Natural gas H 25 mbar (HU) Natural gas L 25 mbar (NL) Liquefied gas G30, 31 28-30/37 mbar Liquefied gas G30 37 mbar (PL) Liquefied gas 50 mbar

• Preset to natural gas (20 mbar)

• Nozzle set for liquid gas nozzles (28-30/37 mbar) included. Nozzles for all other types of gas can be ordered through customer service. To change the nozzle, please contact customer service.

• Dimensions of the device (HxWxD mm): 54 x 915 x 520

• Required niche dimensions (HxWxD mm): 45 x 850 x (490 - 500)

• Required niche dimensions for flush installation (HxWxD mm): 45 x 919 x 524

• Minimum worktop thickness: 20 mm

• For flush installation, the minimum worktop thickness is 30 mm.

• Power cable: 1 m

• Total connected load: 12.5 kW

• Germany: Gas hobs with a connected load of more than 11 kW must meet additional requirements, such as: B. controlled room ventilation in extractor hoods in exhaust mode. These may need to be discussed with the installer.

Technical data

• Device type: gas switch recess

• Design: built-in

• Energy source: gas

• Number of cooking zones: 5

• Min. niche dimensions for installation (H x W x D): 45 x 850-850 x 490-500 mm

• Device width: 915 mm

• Dimensions of the device (H x W x D): 54x915x520 mm

• Net weight: 24.2 kg

• Residual heat display: Separate
• Location of the control: Front

• Main surface material: Tempered glass
• Surface color: Black
• Frame color: Black

• Length of connection cable: 100 cm
• EAN number: 4242003948408
• Gas connection value: 12500 W

• Fuse: 3 A

• Voltage: 220-240V

• Frequency: 50; 60Hz
