For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking chamber and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

• FlameSelect: always exactly the right flame strength - with nine predefined power levels.
• Easy to clean: removable knobs and dishwasher-safe pot supports make cleaning pleasant.

• Dishwasher-safe pot supports: make cleaning your gas hob even easier.

• Continuous cast iron pot supports: for high resilience and stability of the cookware.

• Safety gas shutdown: immediate shutdown of the gas supply when the flame goes out.

Burner and performance

• 4 gas hobs, gradually adjustable

• Front left: normal burner up to 1.75 kW (depending on the type of gas)

• Rear left: normal burner up to 1.75 kW (depending on the type of gas)

• Rear right: wok burner up to 3.5 kW (depending on the type of gas)

• Front right: Economy burner up to 1 kW (depending on the type of gas)

Ease of use

• FlameSelect: precisely adjust the flame in nine defined levels.

• Control knob, front: easily accessible and operable knobs in the front area for effortless turning.

• 1-hand ignition: to ignite the flame, simply press and turn the knob.

Design

• Stainless steel surface

• Cast pot support
• Full metal rotary selector

Safety

• Thermoelectric ignition safety device: prevents further gas flow when the flame goes out

Installation

• Can be used for:

  • Natural gas L/LL G25/20 mbar (DE)

  • Natural gas H/E 20 mbar, E+ 20/25 mbar

  • Natural gas H 25 mbar (HU)

  • Natural gas L 25 mbar (NL)

  • Liquefied gas G30, 31 28-30/37 mbar

  • Liquefied gas G30 37 mbar (PL)

  • Liquefied gas 50 mbar

• Preset to natural gas (20 mbar)

• Nozzle set for liquid gas nozzles (28-30/37 mbar) included. Nozzles for all other types of gas can be ordered through customer service. To change the nozzle, please contact customer service.

• Dimensions of the device (HxWxD mm): 51.5 x 582 x 520

• Required niche dimensions (HxWxD mm): 45 x 560 x (480 - 490)

• Minimum worktop thickness: 20 mm

• Power cable: 1 m
• Total connected load: 8 kW

Technical data

• Product name/family: Gas switch recess

• Design: built-in

• Energy source: gas

• Number of cooking zones: 4

• Controls: Sword lever
• Min niche dimensions for installation (H x W x D): 45 x 560 x (480 - 490) mm

• Device width: 582 mm

• Dimensions of the device: 45 x 582 x 520 mm

• Net weight: 10.7 kg

• Residual heat display: without

• Control location: front
• Main surface material: stainless steel
• Surface color: stainless steel
• Connection cable length: 100 cm

• EAN number: 4242005495962
• Gas connection value: 8000 W
• Fuse: 3 A
• Voltage: 220-240 V

• Frequency: 50; 60 Hz
