For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

Design

• SchrägEssenDesign

• Device color: black printed

• Wall mounting

• Choice of exhaust air or recirculation mode

• Chimney-free operation possible with recirculated air

• The Clean Air Plus recirculation set (accessory) or the Longlife recirculation set (accessory) is required for recirculation operation.

Most important features

• BLDC Motor

• 2 pieces, LED, 3 W, with color temperature adjustable

• Soft Light

  The dim light emitted from the Soft Light keypad allows you to see the speed level of the hood at a glance.

  : the lighting turns on and off gently.

• Dimming function: the brightness of the lighting can be adjusted.

• Color temperature: 3500 K

• Illuminance: 502 lux

• 2 detection surfaces: front and bottom

• 2 metal grease filters

Comfort functions

• Touch Select operation, backlit

• 3 performance levels and 1 intensive level

• Automatic fan run-on with digital display

• Automatic reset from intensive to normal level after 6 minutes

Digital functions

• Home Connect

  Control of the device via app; It is also possible to have suitable settings or programs suggested



• Hob-based hood control

• Hob hood connection

• Smart Hood Automatic: Fully automatic extractor hood

• Voice control possible via common voice assistants

• Performance profiles: Standard, Quiet and Power

• LED lighting with adjustable light temperature

• Saturation display, setting and reset function for grease filters and odor filters available via the Home Connect app.

• Overrun function: available via Home Connect app

• Interval function: available via Home Connect app

• Upgradable device

Convenience in cleaning

• Extremely large opening angle for easy access to the filter and easy cleaning.

• The surfaces and materials are smooth and easy to clean.

• Metal grease filter, dishwasher safe

Environment and safety

• Energy efficiency class: A+

• Average energy consumption: 31.7 kWh/year

• Fan efficiency class: A

• Lighting efficiency class: A

• Grease filter efficiency class: C

Output exhaust air

• According to EN 61591 and EN/IEC 60704213, your device can achieve the following values ​​in exhaust air mode
• reach:

• Performance level 3: Fan performance: 431 m3/h; Noise value: 56 dB (A) re1pW

• Intensive level 2: Fan performance: 768 m3/h; Noise value: 68 dB (A) re1pW

Power recirculation

• According to EN 61591 and EN/IEC 60704213, your device can achieve the following values ​​in recirculation mode with the Clean Air Plus recirculation set for installation with a chimney:

• Performance level 3: Fan performance: 429 m3/h; Noise value: 62 dB (A) re1pW

• Intensive level 2: Fan performance: 724 m3/h; Noise value: 74 dB (A) re1pW

• According to EN 61591 and EN/IEC 60704213, your device can achieve the following values ​​in recirculation mode with the Clean Air Plus recirculation set for chimney-free installation
• Performance level 3: Fan performance: 427 m3/h; Noise value: 64 dB (A) re1pW

• Intensive level 2: Fan performance: 687 m3/h; Noise value: 76 dB (A) re1pW

Technical information

• Device dimensions, exhaust air (HxWxD): 883-1126 x 590 x 433 mm

• Device dimensions for circulating air (HxWxD): 883-1213 x 590 x 433 mm

• Exhaust air connection Ø 150 mm

• Total connected load: 140 W

• Voltage: 220 240 V

• Length of connection cable: 1.3 m with plug

• Delivery with backflow flap

Sustainability

• Made in Germany: manufactured in a CO2-neutral production facility

• Environmentally friendly packaging

• The most efficient fan technology on the market

• Hob hood connection for best results with minimal energy consumption
