For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

• Particularly quiet: the high-performance hood that hardly makes any noise.

• Eco Silence Drive™: the powerful and energy-saving motor for extractor hoods.

• DirectSelect operation: quickly adjust the extractor hood by touch.

• LED lighting: The energy-saving lighting ensures good and bright illumination of the hob.

• Intensive level: eliminates strong cooking odors particularly quickly and effectively.

Design

• Wall plate, 60 cm

Operating mode and performance

• Noise values ​​according to EN 60704-2-13 for exhaust air operation:

• Max. normal level: 60dB(A) re 1 pW

• Intensive level: 70 dB(A) re 1 pW

• Fan performance according to EN 61591 in exhaust mode:

• Max. normal level: 415m³/h

• Intensive level: 671 m³/h

• When using the separately available Clean Air recirculation set (special accessory), your device achieves the following values ​​in recirculation mode:

• Fan performance: Max. normal level: 330m³/h

• Intensive level: 409m³/h

• Noise values: Max. normal level: 67dB(A) re 1 pW

• Intensive level: 71 dB(A) re 1 pW

• Energy efficiency class: A (on an energy efficiency class scale from A+++ to D)

• Average energy consumption: 36.1 kWh/year*

• Fan efficiency class: A*

• Grease filter efficiency class: B*

• Lighting efficiency class: A*

• EcoSilence Drive

• Noise min./max. Normal level: 47/60 dB

• Even, bright lighting with 2 x 1.5 W LED module

• Illuminance: 267 lux

• Color temperature: 3500 K

Environment and safety

• Metal grease filter, dishwasher safe

Comfort

• Electronic control via DirectSelect operation with LED display

• 3 power levels and

• 1 intensive level

• Intensive levels with automatic reset

• Extremely quiet operation thanks to special noise insulation
• Optional exhaust air or recirculation mode

• Inner frame, easy to clean

• Cassette with aluminum frame

• Delivery with backflow flap

Technical information

• For wall mounting above hotplates

• Quick assembly fastening

• A standard recirculation set or a Clean Air Plus recirculation set (special accessory) is required for recirculation operation
• Device dimensions, exhaust air (HxWxD): 614-954 x 598 x 500 mm

• Exhaust air connection Ø 150 mm (Ø 120 mm included)

• Device dimensions for circulating air (HxWxD): 614-1064 x 598 x 500 mm

• Device dimensions recirculation air with Clean Air Plus recirculation set (HxWxD):

• 689 x 598 x 500mm - mounting on external channel

• 795-1139 x 598 x 500 mm - mounting on inner channel

• Total connected load: 143 W

• Length of connection cable: 1.3 m with plug

• Voltage: 220 - 240 V

Technical data

• Type: wall mounting

• Length of connection cable: 130.0 cm

• Chimney height: 582-908/568-1018 mm

• Device height: 46 mm

• Minimum distance to the electric hob: 550 mm

• Minimum distance to the gas hob: 650 mm

• Net weight: 15.0 kg

• Control: electronic

• Max. fan output exhaust air: 414 m³/h

• Fan performance in intensive level recirculation mode: 409 m³/h

• Max. fan output for circulating air: 330 m³/h

• Fan performance in intensive exhaust mode: 671 m³/h

• Number of lamps (pcs): 2

• Sound power: 60 dB(A) re 1 pW

• Diameter of the exhaust air connection: 150 / 120 mm

• Grease filter material: washable aluminum
• EAN number: 4242005086597

• Connection value: 143 W

• Fuse: 10 A

• Voltage: 220-240V

• Frequency: 60; 50Hz

• Plug type: Schuko/Gardy with grounding

• Device type: Wall mounting

* According to EU regulation No. 65/2014
