For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking chamber and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

• Eco Silence DriveTM: the quiet, energy-saving and powerful motor for extractor hoods.
• Smart Hood Automatic: automatically adjusts the fan performance based on hob data* for relaxed cooking.

• DirectSelect: easy selection of the desired power and light settings.

• LED lighting: The energy-saving lighting ensures good and bright illumination of the hob.

• Dual filter system: efficient and long-lasting air and odor filtration.

Design and most important properties

• Wall mounting

• Choice of exhaust air or recirculation mode
• Eco Silence Drive: the powerful and energy-saving motor

• 2 x LED 3 W with color temperature adjustable

• Soft Light

  The dim light emitted from the Soft Light keypad allows you to see the speed level of the hood at a glance.

  : the lighting turns on and off gently.

• Dimming function: the brightness of the lighting can be adjusted.

• Color temperature: 3500 K

• Illuminance: 461 lux

• 3 metal grease filters - dishwasher safe

Comfort functions

• Glass device front with integrated controls for easy operation

• Electronic control via DirectSelect operation, backlit

• 3 performance levels and 1 intensive level

• Automatic reset of Intensive

• to normal level after 6 minutes

• Fan run-on 10 minutes
• The surfaces and materials are smooth and easy to clean.
• Coated surface to reduce fingerprints.

Digital functions

• Home Connect

  Device control option via app; It is also possible to have suitable settings or programs suggested

  : Operation, checking and setting of the extractor hood via smartphone or tablet (only in countries where the Home Connect service is available)

• The hob-based hood control activates the extractor hood automatically when cooking, thanks to the WiFi connection of the extractor hood and a suitable hob.

• Smart Hood Automatic: The extractor hood automatically adjusts the fan power as the hob continuously sends cooking data (works with all current Series 6 induction hobs; for other Home Connect hobs, the extractor hood can be controlled directly from the hob if a connected Home Connect account is available)

• Voice control possible via common voice assistants

• Performance profiles: Choose between Standard, Performance or Quiet in the Home Connect app to increase fan performance or reduce noise

• LED lighting with adjustable light temperature: Allows you to adjust the light temperature to personal needs via the Home Connect app

• Saturation display, setting and reset function for grease filters and odor filters available via the Home Connect app.

• Overrun function: available via Home Connect app

• Interval function: available via Home Connect app

• The Home Connect functionality can be expanded as desired by integrating numerous applications from external cooperation partners (partnering).
• Updateable device (available with a connected Home Connect account): Always keep the device up to date with the latest software.

Exhaust air mode

• According to EN 61591 and EN/IEC 60704-2-13, the device can achieve the following values ​​in exhaust air mode:

  • Performance level 1: Fan performance 242 m3/h; Noise value 43 dB(A) re1pW

  • Performance level 2: Fan performance 335 m3/h; Noise value 51 dB (A) re1pW

  • Performance level 3: Fan performance 399 m3/h; Noise value 56 dB (A) re1pW

• Intensive level 1: fan performance 699 m3/h; Noise value 68 dB (A) re1pW

• Energy efficiency class: A++ (on an energy efficiency class scale from A+++ to D)

• Average energy consumption: 24.5 kWh/year*

• Fan efficiency class: A*

• Lighting efficiency class: A*

• Grease filter efficiency class: B*

Recirculation mode

• A Long-Life Clean Air recirculation set (special accessory) is required for recirculation mode - The Long-Life Clean Air odor filter absorbs intense odors, such as: B. fish, as well as pollen. The service life can be extended up to 4 times by refreshing the filter in the oven - According to EN 61591 and EN/IEC 60704-2-13, the device can achieve the following values ​​in recirculation mode with the Long-Life Clean Air recirculation set (available as an optional accessory):

  • Performance level 1: Fan performance 239 m3/h; Noise value 50 dB(A) re1pW

  • Performance level 2: Fan performance 334 m3/h; Noise value 59 dB(A) re1pW

  • Performance level 3: Fan performance 410 m3/h; Noise value 64 dB(A) re1pW

  • Intensive level 1: fan performance 677 m3/h; Noise value 73 dB (A) re1pW

Technical data and sustainability

• Consumption information:

  • Total connected load: 115 W

  • Voltage: 220 - 240 V

• Sustainability:

  • Made in Germany: manufactured in a CO2-neutral production facility

  • Environmentally friendly packaging

  • The most efficient fan technology on the market

  • Available Long-Life Clean Air odor filter with up to 4 times longer lifespan

Information on planning and installation

• Less installation effort thanks to the simple assembly system
• Device dimensions, exhaust air (HxWxD): 635-895 x 898 x 500 mm

• Device dimensions for circulating air (HxWxD): 803-943 x 898 x 500 mm

• Exhaust air outlet: Ø 150 mm

• Length of connection cable: 1.3 m with plug

Technical data

• Type: wall mounting

• Length of connection cable: 130.0 cm

• Device height: 60 mm

• Minimum distance to the electric hob: 550 mm

• Minimum distance to the gas hob: 650 mm

• Net weight: 14 kg

• Control: electronic

• Fan performance at the highest normal level, exhaust air: 399 m³/h
• Fan performance at the intensive level, recirculation air:: 677 m³/h

• Fan performance at the highest normal level circulating air:: 410 m³/h

• Fan performance at intensive exhaust level: 699 m³/h

• Max. air volume: 399 m³/h
• Number of lamps (pcs): 2

• Sound power: 56 dB(A) re 1 pW

• Diameter of the exhaust air connection: 150 mm
• Grease filter material: metal grease filter - washable
• EAN number: 4242005530526
• Connected load: 115 W

• Fuse: 10 A

• Voltage: 220-240V

• Frequency: 50 Hz

• Plug type: Schuko/Gardy with grounding

• Device type: Wall mounting

* According to EU regulation No. 65/2014
