For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

Equipment:

• Material: VB ceramic
• Color: SM Steam from the Classicline series
• CeramicPlus (VB-Ceramicplus)

• 1 basin

Technical information:

• minimum base cabinet width 45 cm
• worktop recess 445 x 480 mm
• sink dimensions: L x W 475 x 510 mm
• basin depth: 225 mm
Hole holes Ø 35 mm ( standardized)

• this sink can only be installed as a built-in or overlay sink; Flush installation or use as an undermount sink is not possible! However, there are sister variants of this model that are intended for substructure or flush installation (at the end "50 SU" for the substructure or "50 S Flat" for the flush variant)

Options to be selected ( please select these at the top right, next to the article photo):

• option "drain set with manual operation" or "drain set with eccentric operation

  The sink is filled and drained using a round rotary knob on the top of the sink. This toggle, called the eccentric actuation, closes or opens the sink drain, depending on which direction it is turned. This eliminates the need to reach into the rinse water.

  " :
  Here you can choose whether you want to close and open the water drain by manually (VB manual operation) or more conveniently using a rotary knob on the top of the sink (VB eccentric operation).
• "Standard pre-drilling" option: The delivery condition of the sink includes pre-punched holes (standard pre-drilling); The top of the sink is closed and must be pierced on site at the marked points.
• "Hole drilling by manufacturer" option: If you would like the hole drilling to be made at the factory by the manufacturer for safety reasons, please select this option. For this we need the numbers/positions of the tap hole(s) that V & B should drill for you. For the sink version with manual operation you need 1 tap hole for the fitting; for the version with eccentric operation you need 2 hole holes (faucet and eccentric operation). Please note the dimensional drawings shown below, as the positions of the hole holes in reversible sinks can be different for the bowl left and bowl right versions. A possible third hole for a soap dispenser can of course also be selected.

• Indication of the hole drilling positions: At the end of your ordering process on our website (at the very bottom of the ordering step of the payment method selection) you will find a comments field below. Please tell us the position numbers there. If you miss this window, please feel free to send us an email to info@ascasa.de. We will of course complete your order accordingly before it is processed further.

Included in delivery depending on the selected option:

• Drain and strainer basket chrome-plated
• For the version with eccentric operation: cover cap for eccentric operation in stainless steel look.
• If you want a chrome version or a square design instead, please select the desired rotary handle from the optional extras available for a fee below.
