For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

Hob features

• Device type: induction cooking area
• with integrated suction
• width: 75 cm

• Device corner radius: 1.5 mm

• Frame DualDesign

Features hob

• Premium Swiss Quality
  Developing and producing innovative, high-quality products at the highest possible technological level is a tradition in Switzerland. The family business V-ZUG AG, founded in 1913, has repeatedly succeeded in making a name for itself in the industry. It is known for regularly developing and bringing world firsts to market. With these milestones, V-ZUG continues to set a sustainable and noble example in the industry.


• Hob: Induction
• V-ZUG PowerPlus

  If PowerPlus is switched on, the selected cooking zone

  works at extra high power for a period of 10 minutes.

  After 10 minutes it automatically switches back to power level 9

  . With PowerPlus you can e.g. B. a large amount of

  Water can be heated quickly.

• Automatic switch-off
• Residual heat display
• Timer
• Cooking zones: 4 (2 at the front with 3000W, 2 at the back with 3700W)

• V-ZUG OptiGlass
• Pot base detection (10-22cm)

Fan equipment

• V-ZUG grease filter

  The exclusive program for the ideal cleaning of extractor hood grease filters. The rinsing process is designed in such a way that the various layers of aluminum knitted metal inside the grease filters are cleaned gently but still very effectively. This guarantees a long service life for the grease filters!

  cleaning indicator

  After 15 hours of operation or at the latest 14 days after

  the indicator lights up for the first time. The saturation level has been reached and the grease filter needs to be cleaned. With optimal care

  the lifespan of a grease filter is almost unlimited.

• Display carbon filter saturation

• Intensive level

• Automatic overrun

• V-ZUG wipe protection button

  This function prevents the power level from being changed unintentionally

  if, for example. B. wipe the control panel with a cloth.

• Exhaust air

• circulating air

• Edge suction

  The rising vapor is sucked off the outer edges of the hood body construction and directed to the grease filter behind it. Due to the high flow speed at the edge of the extractor hood, almost no cooking fumes can escape into the kitchen, even with lower motor settings. There are no turbulences, the drag effect is high and rebound effects play no role. The air does not flow into the kitchen, but directly into the extractor hood. The increase in efficiency resulting from edge extraction enables operation at lower power levels, with less energy consumption and lower noise.



• OptiLink

Features Fan

• 9 power levels

• Intensive level with automatic reset

• removable drip tray (integrated grease filter, 500 ml capacity, dishwasher safe)

Operation & displays

• Touch graphic display
• On time
• Languages ​​in the display: 9
• Operation: TouchControl

• Key tone setting (on/off)

Functions

• V-ZUG PowerPlus
• V-ZUG pause button

  With this function, all cooking zones can be temporarily switched to power level 1 for a maximum of 10 minutes

  . Operation can be continued with the selected settings after

  a cooking break.

• V-ZUG warming function

  You have stood in the kitchen for hours and have prepared the perfect dinner

  for your guests. The first course is served and you are eating.

  But what do you do with the already cooked food until the second service?

  No problem with the new keep warm function. This way you can shine again in the second

  round.

• V-ZUG automatic heating system

  With the automatic heating system, a cooking zone works at full power for a certain period of time after it is switched on

  . After this duration

  it automatically switches back to the set power level.

• acoustic timer
• ice-on time with switch-off function
• V-ZUG wipe protection button
• V-ZUG melting function

  Melt for example butter,

  chocolate or honey gently at 40°C.



• V-ZUG Simmering function

  The hob keeps the temperature constantly below the boiling point.

  This function prevents sausages from bursting, for example.

  Is ideal for sausages, stuffed pasta, dumplings and pasta.



• V-ZUG child lock

  The child lock is intended to prevent unintentional switching on.

Energy values ​​

• Max. power cooking zone 1: 3000.0 W
• Max. power cooking zone 2: 3000.0 W

• Max. power cooking zone 3: 3700.0 W

• Max. power cooking zone 4: 3700.0 W

• Rated voltage (1): 400V 3N~

• Rated voltage (2): 230 V~

• Frequency (1): 50 Hz

• Frequency (2): 50 Hz

• Plug type: Cable


Dimensions

• Cutout height 8.5 mm

• Cutout radius 5.0 mm

• Device height 206.0 mm

• Device width 761.0 mm

• Device depth 501.0 mm

• Device corner radius 1.5 mm

• Overlay width 750.0 mm

• Support width max. 750.0 mm

• Support depth 490.0 mm

• Support depth max. 490.0 mm

• Installation height flush 206.0 mm

• Installation height lying on 202.0 mm

• Cutout width flush 767.0 mm

• Cutout width on top 750.0 mm

• Cutout width on top max. 750.0 mm

• Cut-out depth flush 507.0 mm

• Cut-out depth on surface 490.0 mm

• Cut-out depth on surface max. 490.0 mm

• Empty weight 20.0 kg

• Dimensions of cooking zone 1 18 cm

• Dimensions of cooking zone 2 21 cm

• Dimensions of cooking zone 3 21 cm

• Dimensions of cooking zone 4 18 cm
