V-ZUG GKD46TIMASZO, 3109460415, trough fan, 10 YEAR WARRANTY!

V-ZUG GKD46TIMASZO, 3109460415, trough fan, 10 YEAR WARRANTY!

V-ZUG GKD46TIMASZO, 3109460415, trough fan, 10 YEAR WARRANTY!

V-ZUG GKD46TIMASZO, induction hob with integrated extractor extraction, 75 cm, dual design, touch graphic display, digital display, TouchControl operation, eco standby, 4 cooking zones, 9 power levels, PowerPlus, OptiGlass, automatic boil-on, child lock
Read more
Vendor code: 3109460415
Delivery time: 10-12 days
9 257.00€


Add to cart

For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

VZug GKD46TIMASZO, induction hob, OptiGlass, 3109460415, INCLUDING 10 YEAR manufacturer's guarantee! * (Manufacturer's warranty conditions)

This device is a version intended for the European market and is not a re-import device with Swiss connection and equipment specifications.

Hob features

  • Device type: induction cooking area
  • with integrated suction
  • width: 75 cm
  • Device corner radius: 1.5 mm
  • Frame DualDesign

Features hob

  • Premium Swiss Quality
    Developing and producing innovative, high-quality products at the highest possible technological level is a tradition in Switzerland. The family business V-ZUG AG, founded in 1913, has repeatedly succeeded in making a name for itself in the industry. It is known for regularly developing and bringing world firsts to market. With these milestones, V-ZUG continues to set a sustainable and noble example in the industry.

  • Hob: Induction
  • V-ZUG PowerPlus

    If PowerPlus is switched on, the selected cooking zone

    works at extra high power for a period of 10 minutes.

    After 10 minutes it automatically switches back to power level 9

    . With PowerPlus you can e.g. B. a large amount of

    Water can be heated quickly.

  • Automatic switch-off
  • Residual heat display
  • Timer
  • Cooking zones: 4 (2 at the front with 3000W, 2 at the back with 3700W)
  • V-ZUG OptiGlass
  • Pot base detection (10-22cm)

Fan equipment

  • V-ZUG grease filter

    The exclusive program for the ideal cleaning of extractor hood grease filters. The rinsing process is designed in such a way that the various layers of aluminum knitted metal inside the grease filters are cleaned gently but still very effectively. This guarantees a long service life for the grease filters!

    cleaning indicator

    After 15 hours of operation or at the latest 14 days after

    the indicator lights up for the first time. The saturation level has been reached and the grease filter needs to be cleaned. With optimal care

    the lifespan of a grease filter is almost unlimited.

  • Display carbon filter saturation
  • Intensive level
  • Automatic overrun
  • V-ZUG wipe protection button

    This function prevents the power level from being changed unintentionally

    if, for example. B. wipe the control panel with a cloth.

  • Exhaust air
  • circulating air
  • Edge suction

    The rising vapor is sucked off the outer edges of the hood body construction and directed to the grease filter behind it. Due to the high flow speed at the edge of the extractor hood, almost no cooking fumes can escape into the kitchen, even with lower motor settings. There are no turbulences, the drag effect is high and rebound effects play no role. The air does not flow into the kitchen, but directly into the extractor hood. The increase in efficiency resulting from edge extraction enables operation at lower power levels, with less energy consumption and lower noise.


  • OptiLink

Features Fan

  • 9 power levels
  • Intensive level with automatic reset
  • removable drip tray (integrated grease filter, 500 ml capacity, dishwasher safe)

Operation & displays

  • Touch graphic display
  • On time
  • Languages ​​in the display: 9
  • Operation: TouchControl
  • Key tone setting (on/off)

Functions

  • V-ZUG PowerPlus
  • V-ZUG pause button

    With this function, all cooking zones can be temporarily switched to power level 1 for a maximum of 10 minutes

    . Operation can be continued with the selected settings after

    a cooking break.

  • V-ZUG warming function

    You have stood in the kitchen for hours and have prepared the perfect dinner

    for your guests. The first course is served and you are eating.

    But what do you do with the already cooked food until the second service?

    No problem with the new keep warm function. This way you can shine again in the second

    round.

  • V-ZUG automatic heating system

    With the automatic heating system, a cooking zone works at full power for a certain period of time after it is switched on

    . After this duration

    it automatically switches back to the set power level.

  • acoustic timer
  • ice-on time with switch-off function
  • V-ZUG wipe protection button
  • V-ZUG melting function

    Melt for example butter,

    chocolate or honey gently at 40°C.


  • V-ZUG Simmering function

    The hob keeps the temperature constantly below the boiling point.

    This function prevents sausages from bursting, for example.

    Is ideal for sausages, stuffed pasta, dumplings and pasta.


  • V-ZUG child lock

    The child lock is intended to prevent unintentional switching on.

Energy values ​​

  • Max. power cooking zone 1: 3000.0 W
  • Max. power cooking zone 2: 3000.0 W
  • Max. power cooking zone 3: 3700.0 W
  • Max. power cooking zone 4: 3700.0 W
  • Rated voltage (1): 400V 3N~
  • Rated voltage (2): 230 V~
  • Frequency (1): 50 Hz
  • Frequency (2): 50 Hz
  • Plug type: Cable

Dimensions

  • Cutout height 8.5 mm
  • Cutout radius 5.0 mm
  • Device height 206.0 mm
  • Device width 761.0 mm
  • Device depth 501.0 mm
  • Device corner radius 1.5 mm
  • Overlay width 750.0 mm
  • Support width max. 750.0 mm
  • Support depth 490.0 mm
  • Support depth max. 490.0 mm
  • Installation height flush 206.0 mm
  • Installation height lying on 202.0 mm
  • Cutout width flush 767.0 mm
  • Cutout width on top 750.0 mm
  • Cutout width on top max. 750.0 mm
  • Cut-out depth flush 507.0 mm
  • Cut-out depth on surface 490.0 mm
  • Cut-out depth on surface max. 490.0 mm
  • Empty weight 20.0 kg
  • Dimensions of cooking zone 1 18 cm
  • Dimensions of cooking zone 2 21 cm
  • Dimensions of cooking zone 3 21 cm
  • Dimensions of cooking zone 4 18 cm

* Information about the manufacturer's warranty


The manufacturer offers a 10-year guarantee on the delivered item throughout Germany. If material or manufacturing defects occur during this period, the manufacturer will provide one of the following services at its discretion under the guarantee:
  • Repair of the item V-ZUG GKD46TIMASZO, 3109460415, downdraft fan
  • Exchange for an equivalent or new item V-ZUG GKD46TIMASZO, 3109460415, downdraft fan (possibly also a successor model)
  • In the event of a warranty claim, please contact:

    V-ZUG Europe BV
    Eevee 102
    8530 Harelbeke-Kortrijk
    BELGIUM
    info.be@vzug.com
    Service hotline: 00800 850 850 00

    Note:

    Your statutory warranty rights towards us remain unaffected. If the purchased item is defective, you can contact us in any case, regardless of whether the warranty case occurs and whether the warranty is claimed or not.
