For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards
This device is a version intended for the European market and is not a re-import device with Swiss connection and equipment specifications.
Equipment
- Device type: Induction cooking area with integrated extractor hood
- Width: 80 cm
- BlackDesign
- Frame DualDesign
Features
- Premium Swiss Quality Developing and producing innovative, high-quality products at the highest possible technological level is a tradition in Switzerland. The family business V-ZUG AG, founded in 1913, has repeatedly succeeded in making a name for itself in the industry. It is known for regularly developing and bringing world firsts to market. With these milestones, V-ZUG continues to set a sustainable and noble example in the industry.
- Dishwasher-safe grease filter cassette
- Induction coil type round
- Hob category induction with internal extractor hood
- Automatic switch-off
- Residual heat display
- Timer
- Restore function
- Cooking zones 4
- Power levels 9 + i
- EcoStandby V-ZUG reduces the standby power consumption of the devices to a minimum. Thanks to EcoStandby, the devices no longer consume any electricity when switched off.
Operation & Displays
- Display graphic display Touch
- Operation Simple Slider
- Slider operation
- Duty cycle
- Number of languages in the display 12
- Setting key tone (on/off)
Functions
- V-ZUG pause button
With this function, all cooking zones can be temporarily switched to power level 1 for a maximum of 10 minutes
. Operation can be continued with the selected settings after
a cooking break.
- V-ZUG automatic warm-up
With the automatic warm-up, a cooking zone works at full power after it is switched on
for a certain period of time. After this period
it automatically switches back to the set power level.
- V-ZUG child lock
The child lock is intended to prevent unintentional switching on.
- V-ZUG PowerPlus
If PowerPlus is switched on, it works the selected cooking zone
for a duration of 10 minutes with an extra high power.
After 10 minutes it automatically switches back to power level 9
. With PowerPlus you can e.g. B. a large amount of
Water can be heated quickly.
- V-ZUG warming function
You have stood in the kitchen for hours and have prepared the perfect dinner
for your guests. The first course is served and you are eating.
But what do you do with the already cooked food until the second service?
No problem with the new keep warm function. So you can shine again in the second
round.
- V-ZUG OptiLink
extractor hood regulates itself automatically in exchange with the hob
- V-Zug warm-up function
Already cooked food can be added 85 °C.
- V-ZUG exhaust air
The cooking fumes are led directly outside through an exhaust pipe.
- V-ZUG recirculating air
Cooking fumes filtered through an activated carbon filter are returned to the room.
- V-ZUG Automatic Temperature
Is ideal when, for example, several portions of omelettes or meat (meat patties) are being prepared. The hob saves the ideal temperature and recalls it quickly with each new portion. The result is even browning. Cooking results for all portions.
- V-ZUG automatic preheating
- V-ZUG wipe protection button
This function prevents the power level from being changed unintentionally
if, for example. B. wiped over the control panel with a cloth.
- V-ZUG melting function
For example, melt butter,
chocolate or honey gently at 40°C.
- V-ZUG Simmering function
The hob keeps the temperature constantly below the boiling point.
This function prevents sausages from bursting, for example.
Is ideal for sausages, filled pasta, dumplings and pasta.
- Safety package
- Pot bottom detection
Energy values
- Consumption standby 0.29 W
- Consumption off state 0 W
- Energy efficiency class A
- Annual energy consumption 34.1 kWh
- Fluid dynamic efficiency 31.7
- Fluid dynamic efficiency class A
- Max. power cooking zone 1 3000 W
- Max. power cooking zone 2 3500 W
- Max. power cooking zone 3 3700 W
- Max. power cooking zone 4 3000 W
- Rated voltage (1) 380-415 V 2N~
- Frequency (1) 50 Hz
- Rated power (1) 7.4 kW
- Fuse value (1) 16 A
- Connector type cable
- Energy consumption cooking zone 1 643320 J/kg
- Energy consumption cooking zone 2 176 Wh/kg
- Energy consumption cooking zone 3 632520 J/kg
- Energy consumption cooking zone 4 633960 J/kg
Dimensions
- Cutout height 8.5 mm
- Cutout radius 5 mm
- Device height 206 mm
- Device width 761 mm
- Device depth 501 mm
- Device corner radius 2 mm
- Overlay width 750 mm
- Support width max. 750 mm
- Support dimension depth 490 mm
- Support depth max. 490 mm
- Installation height flush 206 mm
- Installation height on surface 202 mm
- Cutout width flush 767 mm
- Cut-out width on top 750 mm
- Cut-out width on top max. 750 mm
- Cutout depth flush 507 mm
- Cut-out depth lying on 490 mm
- Cut-out depth on surface max. 490 mm
- Empty weight 17.56 kg
- Position of cooking zone 1, front left
- Dimensions of cooking zone 1 18 cm
- Dimensions of cooking zone 2 21 cm
- Dimensions of cooking zone 3 21 cm
- Dimensions of cooking zone 4 18 cm
