For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards
The rising vapor is sucked off at the outer edges of the hood body construction and directed to the grease filter behind it. Due to the high flow speed at the edge of the extractor hood, almost no cooking fumes can escape into the kitchen, even with lower motor settings. There are no turbulences, the drag effect is high and rebound effects play no role. The air does not flow into the kitchen, but directly into the extractor hood. The increase in efficiency resulting from edge extraction enables operation at lower power levels, with less energy consumption and lower noise.
Almost completely closed with a stainless steel cover, the vapors are completely absorbed in a narrow circumferential opening through an accelerated air flow. Due to the reduced open surface, the Teka extractor hoods produce less noise, including the der DBB 60.Extractor hoods have become an important design element within the kitchen. For this reason, Teka is expanding the hood range not only to include traditional but also avant-garde models.
Equipment of the DBB60
- Wall mounting
- fully welded corners
- Telescopic fireplace
- DT motor
- Exhaust air output, free-blowing 475 m³/h (according to UNE-EN-61591 405 m³/h, level 3)
- Exhaust air mode
- Recirculating air mode possible (see optional accessories)
- Lighting 2 x 40 W
- 3-stage power control
- Metal grease filter
- LED -Operation display
- Control panel with pushbuttons
- Recirculating air set incl. carbon filter (item no. 40490116 for an additional charge)
- Connected load 220 W
- Noise at max. normal operation 405 m³/h: 54 dB(A) corresponds to 63 dB(A ) (re 1 pW) according to DIN/EN 60704-2-13
Special accessories (not included in delivery - to be purchased separately)
- Teka carbon filter D4C, 61801262
* Information about the manufacturer's warranty
The manufacturer offers a 5-year guarantee throughout Germany on the delivered item Teka DBB 60, chimney hood, stainless steel, 60 cm. If material or manufacturing defects occur during this period, the manufacturer will provide one of the following services at its discretion under the guarantee:
Küppersbusch Hausgeräte GmbH
TEKA Germany
Küppersbuschstrasse 2
D-45883 Gelsenkirchen
Telephone: +49 209 401-631
Fax: +49 209 401-715
Email: teka@kueppersbusch.de
Note:
Your statutory warranty rights towards us remain unaffected. If the purchased item is defective, you can contact us in any case, regardless of whether the warranty case occurs and whether the warranty is claimed or not.
