What is the Switch?
Installing an extractor hood has not been free of complications. During the planning stage, many factors had to be taken into account, long-term decisions had to be made and a number of manufacturer's instructions had to be paid attention to.
Above all, the decision between recirculation or exhaust air system deprived the buyer of any flexibility. This was not only unsatisfactory for the customer, but especially for you as a professional. Until now!
SilverSwitch – the solution!
SilverSwitch now makes it particularly easy for you, as you no longer have to decide between installing a recirculation or exhaust air system when planning your customers' kitchen. Because SilverSwitch can do both.
Thanks to SilverSwitch, you can switch between recirculation and exhaust air mode as you wish. This ensures a flexible climate in the kitchen. The best thing: The SilverSwitch can be easily combined with almost all exhaust-operated SILVERLINE hoods. Retrofitting is also possible quickly and easily.
The advantage for the end customer:
The user can save heating costs in winter or when outside temperatures are cool by no longer simply releasing warm air outside.
In summer or during intensive cooking, however, odors are completely transported outside into the open air.
Very flexible and very simple. With the SilverSwitch.
The Switch Effect
The SilverSwitch principle is as ingenious as it is simple: At the push of a button, the sucked-in air is simply deflected into the selected exhaust or recirculation air direction by a motor-driven switch - i.e. either the room air is returned, cleaned through the activated carbon filters and the ventilation slots, or returned as exhaust air through the wall outlet into the room Free directed. When recirculating air, the activated carbon filter pads neutralize existing odors.
The SilverSwitch module can be installed in almost all exhaust air-operated SILVERLINE wall and island hoods that are operated with a chimney shaft. It is even possible to retrofit SilverSwitch into these hoods. *)
SilverSwitch
The SilverSwitch allows you to flexibly choose between recirculation or exhaust air operation of a SILVERLINE extractor hood at any time! Set SSD-I32ES for Silverline island hood
- Vela Isola Premium Black/Black Glass
- SilverSwitch is a system for practical switching between recirculated air and exhaust air, which ensures a flexible climate in the kitchen.
- SilverSwitch can be switched using a switch positioned on the side of the shaft. The air is directed in the desired exhaust or recirculation direction by a motor-driven switch according to the setting.
- The Switch Effect
The SilverSwitch principle is as ingenious as it is simple: At the push of a button, the sucked-in air is simply deflected into the selected exhaust or recirculation air direction by a motor-driven switch - i.e. either the room air is returned, cleaned through the activated carbon filters and the ventilation slots, or returned as exhaust air through the wall outlet into the room Free directed. When recirculating air, the activated carbon filter pads neutralize existing odors.
The SilverSwitch module can be installed in almost all exhaust air-operated SILVERLINE wall and island hoods that are operated with a chimney shaft. It is even possible to retrofit SilverSwitch into these hoods.
- 1 x SilverSwitch module, 1 x stainless steel chimney (inner shaft), side adapter for carbon filter, 2 x activated carbon filter pad AFP-SET 902 (washable up to 3 times) + stainless steel cover, Mounting material
- The exhaust air connection can be flexibly placed over the SilverSwitch module backwards through the wall, upwards and to the left or right to the sides.*
* If the exhaust air is routed to the side through the stainless steel chimney, an additional special shaft is required.
SilverSwitch can also be operated in conjunction with a window contact switch.
- SilverSwitch can be installed in almost all SILVERLINE wall and island hoods that are operated in exhaust mode in conjunction with a chimney shaft. *)
SILVERLINE extractor hoods can be retrofitted with SilverSwitch, provided there is a minimum distance of 529 mm from the top edge of the motor box of the hood to the bottom edge of the exhaust air hole in the wall (see drawing). The SilverSwitch module requires its own power supply and therefore an additional socket connection.
* SilverSwitch cannot be operated with the following hood models:
Wall hoods: Comet Premium, Polaris Deluxe, Antares Deluxe, Shadow Deluxe, Carisma, Carisma Deluxe,
Drena, Basic, Venus, Lara
Island hoods: Comet Isola Premium, Polaris Isola, Antares Isola
The installation of SilverSwitch is not possible with table hoods, ceiling hoods, corner hoods, flat screen hoods, under-unit hoods and fan modules.
- For connecting the extractor hood with SilverSwitch: Alu-Flex hose, item no. AFS 150 and hose clamps item no. SS 150.
- For connecting SilverSwitch to the exhaust air outlet: Recommended: smooth-walled round pipe, Ø 150 mm, smooth-walled 90˚ round pipe bend; Alternatively: Alu-Flex hose, item no. AFS 150 and hose clamps item no. SS 150.
