For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards
Silverline SHUD 124S ceiling hood
- No casing of the ceiling required - no installation of exhaust ducts necessary
- Quick and easy assembly thanks to separate components (motor box and housing body)
- Attach the device in 2 steps, only 1 to 2 people required
- Simple planning: To avoid air turbulence, the 2 recirculating air outlets can now be flexibly adjusted before installation - possible in all 4 directions
- Edge suction
The rising vapor is sucked off the outer edges of the hood body construction and directed to the grease filter behind it. Due to the high flow speed at the edge of the extractor hood, almost no cooking fumes can escape into the kitchen, even with lower motor settings. There are no turbulences, the drag effect is high and rebound effects play no role. The air does not flow into the kitchen, but directly into the extractor hood. The increase in efficiency resulting from edge extraction enables operation at lower power levels, with less energy consumption and lower noise.
- All-round LED lighting
- Remote control included
- Color: black (also available in white)
- only recirculation mode
Fan performance
- Max. 750 m3/h free-blowing, min./max. Normal operation 367/620 m3/h, EBM-Papst engine
- Fan performance measured according to DIN EN 61591 and noise according to DIN EN 60704-2-13.
Control
- 4 normal levels / electronics with 15-minute automatic overrun, including remote control (FB 2) and installation kit
- Automatic safety shutdown after 4 hours of operation
- Can only be controlled via remote control!
Technical data
- Lighting: 1 x 33 W LED light strip, daylight white 6500 Kelvin
- Connected load: max. 137 W
- 4 x dishwasher-safe stainless steel metal grease filters
- Noise values: Min./Max. Normal operation 64/77 dB(A)
Special features
- Recommended installation height from the floor to the lower edge of the hood max. 2.50 m.
- Distance from hob to ceiling hood maximum 150 cm
- The Light Box is supplied with the recirculation starter set consisting of 2 x activated carbon honeycomb filter box and 2 x activated carbon honeycomb filters (AF-SET 913 for white version, AF-SET 914 for black version) already included.
