For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

Silverline FLHK 800 ESK HighLight hob with hob extractor

• Hob and extractor in one device

• Installation in standard carcass possible from a depth of 560 mm

• Easy accessibility for easy cleaning and care by removing the inner part of the hood, capacity of the liquid collection container 0.5 liters
• Low installation height as well as quick and easy installation

• The purified air is returned to the kitchen through the circulating air filter unit. This means that no moisture collects inside the kitchen cabinet or in the base, causing moisture damage and mold growth.

• Hob with powerful output of 6,400 W,

• Both edge suction

  The rising vapor is sucked off the outer edges of the hood body construction and directed to the grease filter behind it. Due to the high flow speed at the edge of the extractor hood, almost no cooking fumes can escape into the kitchen, even with lower motor settings. There are no turbulences, the drag effect is high and rebound effects play no role. The air does not flow into the kitchen, but directly into the extractor hood. The increase in efficiency resulting from edge extraction enables operation at lower power levels, with less energy consumption and lower noise.

  Slabs in stainless steel and black glass included in delivery
• Flush installation or support mounting possible / with integrated base motor
• Exhaust air and recirculation operation possible

Hob extractor:

• Fan performance: Max. 700 m3/h free-blowing, EBM-Papst base motor

• Min./Max. Normal operation 314/648 m3/h*

• Control: 4-stage touch control LED electronics on the hob with 15-minute automatic overrun and grease filter cleaning indicator

• Exhaust air connection: Connection for flat duct, nozzle dimensions = 222 x 89 mm; Exhaust air connection possible on the left or right by turning the exhaust air box.

• Connection to the motor with 150mm round pipe, outlet from the motor with flat duct 222 x 89 mm. Exhaust air outlet possible by rotating the motor in all directions.

• For recirculating air mode: additionally Recirculating air starter set 811 (activated carbon honeycomb filter box incl. 1 x AF 811) required.

• Grayness values: Min./Max. Normal operation 54/71 dB(A)*

• Connected load: Max. 150 W / Average energy consumption: 46 kWh/year
• Grease filter: 1x dishwasher-safe stainless steel metal grease filter, 16 layers
• Operating mode: Exhaust air or recirculation mode possible. Powerful air recirculation operation can also be carried out with the ZKM 800 or ZKM 1200 intermediate chamber motors. This model is equipped with an integrated motor. Optionally and free of charge (excluding external motor) it can be converted to operation with an external motor (see special accessories for external motors).
• Special features: Both edge suction plates in stainless steel and black glass included in delivery.

Hob:

• Ease of use: Operation via sensor buttons, digital display of the power levels (color red)

• 9 power levels per cooking zone

• Automatic heating
• Cooking zone equipment : 4 HighLight cooking zones

• Front left: Ø 135 mm / 1,000 W - switchable dual-circuit zone Ø 210 mm 2,200 W
• Rear left: Ø 145 mm / 1,200 W

• Front right: Ø 145 mm / 1,200 W

• Rear right: Ø 180 mm / 1,800 W
• Safety functions: Safety switch-off
• Locking function
• Residual heat display for each cooking zone
• Overheating protection
• Protection against incorrect connection

• Connected load/consumption: Total connected load 6,400 W,

• front left - Ø 210/135 mm: 171.1 Wh/kg - standardized cookware category C

• rear left: Ø 145 mm: 173.8 Wh/kg - standardized cookware category A

• front right: Ø 180 mm: 191.3 Wh/kg - standardized cookware category B

• rear right: Ø 145 mm: 173.8 Wh/kg - standardized cookware category A

• Energy consumption of the EChob hob 180 Wh/kg
• Connection cable without plug, length 140 cm
• Connection voltage: 220-240 V ~50-60 Hz, 1 phase + N, fuse 25 A
• 400 V ~50- 60 Hz, 2 phases + N, fuse 16 A
• Attention: the extractor hood has a separate power connection with power plug (220-240 V ~50 Hz)
• Worktop cutout 750 x 490 mm

* Notes:

Will If a guarantee is stated in the item description, your statutory warranty rights towards us remain unaffected. If the purchased item is defective, you can contact us in any case, regardless of whether the warranty case occurs and whether the warranty is claimed or not.

In the countries Denmark, Czech Republic, Poland, Austria, France, Luxembourg, Belgium, the Netherlands and Switzerland, in the event of damage or repairs, the maximum costs covered under the 5-year guarantee are the amount of the damage or the repair costs would have arisen if they had taken place in Germany.
