For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking chamber and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

Design

• 90 cm

• For ceiling mounting above kitchen islands

Operating mode and performance

• Optional exhaust air or recirculation mode

• Exhaust air performance according to EN 61591:

• max. normal operation 458m³/h

• Intensive level 798 m³/h

• Noise values ​​according to EN 60704-2-13 for exhaust air operation:

• Max. normal level: 56dB(A) re 1 pW

• Intensive level: 68 dB(A) re 1 pW

• When using the separately available Clean Air Plus recirculation set (special accessory), your device achieves the following values ​​in recirculation mode:

• Recirculation level: Max. normal operation: 422m³/h

• Intensive level: 565m³/h

• Noise values ​​for circulating air: Max. normal level: 63dB(A) re 1 pW

• Intensive level: 69 dB(A) re 1 pW

• 3 performance levels + 2 intensive levels

• Intensive level with automatic reset

• Automatic fan run-on

Design

• Edge suction

  The rising vapor is sucked off the outer edges of the hood body construction and directed to the grease filter behind it. Due to the high flow speed at the edge of the extractor hood, almost no cooking fumes can escape into the kitchen, even with lower motor settings. There are no turbulences, the drag effect is high and rebound effects play no role. The air does not flow into the kitchen, but directly into the extractor hood. The increase in efficiency resulting from edge extraction enables operation at lower power levels, with less energy consumption and lower noise.



• Easy-to-clean inner frame made of stainless steel
• Glass filter cover

• Stylish LED lighting behind glass

Comfort

• cookConnect system (with matching hob)

• Remote start and remote monitoring for networking home appliances and operation via smartphone or tablet (only in countries where Home Connect Service is available)

• The Home Connect functionality can be expanded as desired by integrating numerous applications from external cooperation partners (partnering).
• Voice control possible via common voice assistants

• Air quality sensor climateControl: allows the extractor hood to automatically regulate the power levels
• Fully automatic extractor hood

• Metal grease filter, dishwasher safe

• Saturation display for grease and odor filters

• Workplace lighting with 4 x 3 W LED module

• Illuminance: 726 lux

• Color temperature: 3500 K

• Electronic control via remote control

• Infrared remote control

• Interval function: available via Home Connect

• Silence function: available via Home Connect

• iQdrive motor - quiet and powerful motor

• Double-flow high-performance blower

• Rotating fan, air outlet possible from all four sides

Environment and safety

• Energy efficiency class: A (on an energy efficiency class scale from A+++ to D)

• Average energy consumption: 34.7 kWh/year*

• Fan efficiency class: A*

• Lighting efficiency class: A*

• Grease filter efficiency class: E*

• Noise min./max. Normal level: 41/56 dB

Technical information

• Device dimensions (WxD): 900 x 500 mm

• Installation dimensions (HxWxD): 299 x 888 x 487 mm

• Total connected load: 174 W

• Length of connection cable: 1.3 m with plug

• Exhaust air connection ø 150 mm

• Ceiling ventilation white

• 90 cm ceiling ventilation, white

• Dimming function

• softLight

Technical data

• Type: island/ceiling fan

• Length of connection cable: 130.0 cm

• Min. niche dimensions for installation (H x W x D): 299mm x 888.0mm x 487mm mm

• Device height: 300 mm

• Minimum distance to the electric hob: 650 mm

• Minimum distance to the gas hob: 650 mm

• Net weight: 24.1 kg

• Control: electronic

• Number of performance levels: 3 levels + 2 intensive

• Fan performance at the highest normal level for exhaust air: 459 m³/h

• Fan performance at intensive circulating air level: 565.0 m³/h

• Fan performance at the highest normal level circulating air: 422 m³/h

• Fan performance at intensive exhaust air level: 798 m³/h

• Max. air volume: 459 m³/h

• Number of lamps (pcs): 4

• Noise: 56 dB(A) re 1pW

• Diameter of the exhaust air connection: 150 mm
• Grease filter material: washable stainless steel
• EAN number: 4242003831663

• Connection value: 174 W

• Voltage: 220-240V

• Frequency: 50; 60Hz

• Plug type: Schuko/Gardy with grounding

• Device type: Island

* According to EU regulation No. 65/2014
