Design

• Wall mounting
• Choice of exhaust air or recirculation mode

Most important features

• iQdrive motor: quiet and powerful motor
• 2 x LED 3 W with color temperature adjustable
• softLight: the lighting switches on and off gently.
• Dimming function: the brightness of the lighting can be adjusted.
• Color temperature: 3500 K
• Illuminance: 461 lux
• 2 metal grease filters

Comfort

• Glass device front with integrated controls for easy operation
• Electronic control via touchControl operation, backlit
• 3 power levels and 1 intensive level
• Automatic reset from intensive to normal level after 6 minutes
• Automatic fan run-on
• The surfaces and materials are smooth and easy to clean.
• Metal grease filter, dishwasher safe
• Coated surface to reduce fingerprints

Digital functions

• Home Connect

  The device can be controlled using an app; Also possible to have suitable settings or programs suggested

  : Operation, checking and setting of the extractor hood via smartphone or tablet (only in countries where the Home Connect service is available)
• The cookConnect system automatically activates the extractor hood when cooking, thanks to the WiFi connection between the extractor hood and a suitable hob.
• Intelligent automatic extractor hood: The extractor hood automatically adjusts the fan power as the hob continuously Provides cooking data (works with all current induction hobs with touchSlider; with other Home Connect hobs, the extractor hood can be controlled directly from the hob if a connected Home Connect account is available)
• Voice control possible via common voice assistants
• LED lighting with adjustable light temperature: allows the light temperature to be adjusted to personal needs via the Home Connect app
• Overrun function: available via Home Connect app
• Interval function: available via Home Connect app
• The Home Connect functionality can be achieved by integrating numerous applications from external cooperation partners (Partnering) expand as desired

Exhaust air mode

• According to EN 61591 and EN/IEC 60704-2-13, the device can achieve the following values ​​in exhaust air mode:

• Performance level 1: Fan performance 242 m3/h; Noise value 43 dB(A) re1pW

• Performance level 2: Fan performance 335 m3/h; Noise value 51 dB (A) re1pW

• Performance level 3: Fan performance 399 m3/h; Noise value 56 dB (A) re1pW

• Intensive level 1: fan performance 699 m3/h; Noise value 68 dB (A) re1pW

• Energy efficiency class: A++ (on an energy efficiency class scale from A+++ to D)

• Average energy consumption: 24.5 kWh/year*

• Fan efficiency class: A*

• Lighting efficiency class: A*

• Grease filter efficiency class: B*

Recirculation mode

• A Long-Life Clean Air recirculation set (special accessory) is required for recirculation mode

• The Long-Life Clean Air odor filter absorbs intense odors such as: B. fish, as well as pollen. The lifespan can be extended up to 4 times by refreshing the filter in the oven
• According to EN 61591 and EN/IEC 60704-2-13, the device can achieve the following values ​​in recirculation mode with the Long-Life Clean Air recirculation set (available as an optional accessory):

• Performance level 1: Fan performance 239 m3/h; Noise value 50 dB (A) re1pW

• Performance level 2: Fan performance 334 m3/h; Noise value 59 dB (A) re1pW

• Performance level 3: Fan performance 410 m3/h; Noise value 64 dB (A) re1pW

• Intensive level 1: fan performance 677 m3/h; Noise value 73 dB (A) re1pW

Technical data and sustainability

• Information on consumption
• Total connected load: 115 W
• Voltage: 220 - 240 V
• Made in Germany: manufactured in a CO2-neutral production facility
• Environmentally friendly packaging
• The most efficient fan technology on the market
• Available Long-Life Clean Air odor filter with up to 4 times longer service life

Information on planning and installation

• Lower installation effort thanks to the simple assembly system
• Device dimensions for exhaust air (HxWxD): 635-895 x 898 x 500 mm
• Device dimensions for circulating air (HxWxD): 803-943 x 898 x 500 mm
• Exhaust air outlet: Ø 150 mm
• Length of connection cable: 1.3 m with plug

Technical data

• Type: wall mounting

• Length of connection cable: 130.0 cm

• Device height: 60 mm

• Minimum distance to the electric hob: 550 mm

• Minimum distance to the gas hob: 650 mm

• Net weight: 10.8 kg

• Control: electronic
• Number of power levels: 3 fan levels and 1 intensive level
• Fan performance at the highest normal level, exhaust air: 399 m³/h

• Fan performance at intensive circulating air level: 677 m³/h
• Fan performance at the highest normal circulating air level: 410 m³/h

• Fan performance at intensive exhaust level: 699 m³/h
• Max. air volume: 399 m³/h

• Number of lamps (pcs): 2

• Noise: 56 dB(A) re 1pW

• Diameter of the exhaust air connection: 150 mm

• Grease filter material: metal, washable

• EAN number: 4242003969205
• Connected load: 115 W

• Voltage: 220-240V

• Frequency: 50 Hz

• Plug type: Schuko/Gardy with grounding

• Device type: Wall mounting
