Comfort

• Push buttons operation
• 3 power levels
• The surfaces and materials are smooth and easy to clean
• Metal grease filter, dishwasher safe
• Coated surface to reduce fingerprints

Exhaust mode

• According to EN 61591 and EN/IEC 60704-2-13, the device can achieve the following values in exhaust mode:

• Performance level 1: Fan performance 361 m3/h; Noise value 57 dB(A) re1pW

• Performance level 2: Fan performance 469 m3/h; Noise value 63 dB(A) re1pW

• Performance level 3: Fan performance 594 m3/h; Noise value 67 dB (A) re1pW

• Energy efficiency class: B (on an energy efficiency class scale from A+++ to D)

• Average energy consumption: 72 kWh/year*

• Fan efficiency class: B*

• Lighting efficiency class: A*

• Grease filter efficiency class: B*

Recirculation mode

• A Long-Life Clean Air recirculation set (special accessory) is required for recirculation mode

• The Long-Life Clean Air odor filter absorbs intense odors such as: B. fish, as well as pollen. The lifespan can be extended up to 4 times by refreshing the filter in the oven

• According to EN 61591 and EN/IEC 60704-2-13, the device can achieve the following values ​​in recirculation mode with the Long-Life Clean Air recirculation set (available as an optional accessory):

• Performance level 1: Fan performance 360 ​​m3/h; Noise value 60 dB(A) re1pW

• Performance level 2: Fan performance 477 m3/h; Noise value 67 dB(A) re1pW

• Performance level 3: Fan performance 569 m3/h; Noise value 71 dB (A) re1pW

Technical data and sustainability

• Information on consumption
• Total connected load: 200 W
• Voltage: 220 - 240 V
• Made in Germany: manufactured in a CO2-neutral production facility
• Environmentally friendly packaging
• Available Long-Life Clean Air odor filter with up to 4 times longer lifespan

Information on planning and installation

• Lower installation effort thanks to simple assembly system
• Device dimensions of exhaust air (HxWxD): 635-895 x 898 x 500 mm
• Device dimensions circulating air (HxWxD): 803-943 x 898 x 500 mm
• Exhaust air outlet: Ø 150 mm
• Length of connection cable: 1.3 m with plug

Technical data

• Type: wall mounting

• Length of connection cable: 130.0 cm

• Device height: 60 mm

• Minimum distance to the electric hob: 550 mm

• Minimum distance to the gas hob: 650 mm

• Net weight: 13.7 kg

• Control: mechanical

• Number of power levels: 3

• Fan performance at the highest normal level, exhaust air: 594 m³/h

• Fan performance at the highest normal level circulating air: 569 m³/h

• Max. air volume: 594 m³/h

• Number of lamps (pcs): 2

• Noise: 67 dB(A) re 1pW

• Diameter of the exhaust air connection: 150 mm

• Grease filter material: washable aluminum

• EAN number: 4242003976296
• Connected load: 200 W

• Fuse: 10 A

• Voltage: 220-240V

• Frequency: 50 Hz

• Plug type: Schuko/Gardy with grounding

• Device type: Wall mounting
