For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking chamber and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues so that they can then be wiped off much more easily

• iQdrive motor: the quiet, powerful motor for efficient extraction of odors and vapors.

• cookConnect system: regulate the power levels and lighting of the extractor hood directly on the hob.

• touchControl: Trigger power and LED lighting can be adjusted with just one touch.

• LED light with adjustable light temperature: adapt the lighting to your preferences and needs.

• Intelligent automatic extractor: the perfect interaction of hob and extractor hood for more cooking comfort.

Design

• Oblique Esse

• Wall mounting

• Glass pane: black printed

• Optional exhaust air or recirculation mode

• Chimney-free operation possible with recirculated air

• The Clean Air Plus recirculation set (accessory) is required for recirculation operation.

Most important features

• iQdrive motor - quiet and powerful motor

• Lighting: 2 pieces, LED, 3 W, with color temperature adjustable

• softLight: the lighting switches on and off gently.

• Dimming function: the brightness of the lighting can be adjusted.

• Color temperature: 3500 K

• Illuminance: 502 lux

• Extractor hood on the front and bottom

• 2 metal grease filters
• touchControl

• 3 performance levels and 1 intensive level

• Automatic reset from intensive to normal level after 6 minutes

• Automatic fan run-on

Digital functions

• Home Connect

  Control of the device via app; Also possible to have suitable settings or programs suggested

  : Operating, checking and adjusting your hood via smartphone or tablet (only in countries where the Home Connect service is available)

• The cookConnect system activates the extractor hood automatically when cooking, thanks to the WiFi connection of the extractor hood and a suitable hob.

• Hob-hood connection: The extractor hood automatically adjusts the fan speed as the hob continuously provides cooking data (with a suitable hob and connected Home Connect access)

• Fully automatic extractor hood

• Voice control possible via common voice assistants

• Performance profiles: Choose between Standard, Performance or Quiet in the Home Connect app to increase the extraction power or reduce the fan noise.

• LED lighting with adjustable light temperature: Allows you to adjust the light temperature to your personal needs via the Home Connect app

• Saturation display, setting and reset function for grease filters and odor filters available via the Home Connect app.

• Overrun function: available via Home Connect app

• Interval function: available via Home Connect app

• The Home Connect functionality can be expanded as desired by integrating numerous applications from external cooperation partners (partnering).
• Upgradable device (available with connected Home Connect account): Always keep the device up to date with the latest software.

Comfort when cleaning

• Large opening angle of the glass plate with locking function for easy filter access and easy cleaning.

• The surfaces and materials are smooth and easy to clean.

• Metal grease filter, dishwasher safe

Output exhaust air

• According to EN 61591 and EN/IEC 60704-2-13, your device can achieve the following values ​​in exhaust mode:

• Performance level 1: Fan performance: 223 m3/h; Noise value 39 dB(A) re1pW

• Performance level 2: Fan performance: 319 m3/h; Noise value 48 dB (A) re1pW

• Performance level 3: Fan performance: 431 m3/h; Noise value 56 dB (A) re1pW

• Intensive level 1: Fan performance: 768 m3/h; Noise value 68 dB (A) re1pW

• Energy efficiency class: A+ (on an energy efficiency class scale from A+++ to D)

• Average energy consumption: 31.7 kWh/year*

• Fan efficiency class: A*

• Lighting efficiency class: A*

• Grease filter efficiency class: C*

Recirculation air performance

• According to EN 61591 and EN/IEC 60704-2-13, your device can achieve the following values ​​in recirculation mode with the Clean Air plus recirculation set for installation with a chimney:

• Performance level 1: Fan performance: 208 m3/h; Noise value: 47 dB(A) re1pW

• Performance level 2: Fan performance: 309 m3/h; Noise value: 54 dB(A) re1pW

• Performance level 3: Fan performance: 429 m3/h; Noise value: 62 dB(A) re1pW

• Intensive level 1: Fan performance: 724 m3/h; Noise value: 74 dB (A) re1pW

• According to EN 61591 and EN/IEC 60704-2-13, your device can achieve the following values ​​in recirculation mode with the Clean Air plus recirculation set for chimney-free installation:

• Performance level 1: Fan performance: 210 m3/h; Noise value: 46 dB(A) re1pW

• Performance level 2: Fan performance: 300 m3/h; Noise value: 54 dB(A) re1pW

• Performance level 3: Fan performance: 427 m3/h; Noise value: 64 dB(A) re1pW

• Intensive level 1: Fan performance: 687 m3/h; Noise value: 76 dB (A) re1pW

Technical data and sustainability

• Consumption information:

• Voltage: 220 - 240 V

• Total connected load: 140 W

• Sustainability:

• Made in Germany: manufactured in a CO2-neutral production facility

• Environmentally friendly packaging

• The most efficient fan technology on the market

• Hob-hood connection for best results with minimal energy consumption

Information on planning and installation

• Device dimensions, exhaust air (HxWxD): 753-996 x 590 x 433 mm

• Device dimensions for circulating air (HxWxD): 790-1083 x 590 x 433 mm

• Dimensions recirculation mode, chimneyless (HxWxD): 360 mm x 590 mm x 433 mm

• Exhaust air connection Ø 150 mm

• Length of connection cable: 1.3 m with plug

• Delivery with backflow flap

* According to EU regulation No. 65/2014
