For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking chamber and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

Design

• Glass ceramic surface, black

• Facet front and back, profiles on the side, aluminum, brushed

• Cast iron pot support

• BSH flat burner: elegant burner design with fewer parts

Burner and performance

• 5 gas burners

• Includes 1 dual wok burner: Use a particularly wide power range and control two flame rings separately.

• Left: Wok burner up to 6.1 kW (depending on the type of gas)

• Front center: Normal burner up to 1.9 kW (depending on the type of gas)

• Rear center: Economy burner up to 1.1 kW (depending on the type of gas)

• Rear right: Power burner up to 2.8 kW (depending on the type of gas)

• Front right: normal burner up to 1.9 kW (depending on the type of gas)

Ease of use

• stepFlame technology - power control in 9 levels: Adjust the flame precisely in nine defined levels.

• Dishwasher safe pot supports: Easy to clean in the dishwasher.

• Integrated switches: easily accessible and operable toggles in the front area for effortless turning.

• One-handed ignition: To ignite the flame, simply press and turn the knob.

Environment and Safety

• Ignition safety device: prevents further gas flow when the flame goes out.

• Can be used for: Natural gas L/LL G25/20mbar (DE)

• Natural gas H/E 20mbar,E+ 20/25mbar Natural gas H 25 mbar (HU) Natural gas L 25 mbar (NL) Liquefied gas G30.31 28-30/37mbar Liquefied gas G30 37 mbar (PL) Liquefied gas 50 mbar

• Preset to natural gas (20mbar)

• Nozzle set for liquid gas nozzles (28-30/37mbar) included. Nozzles for all other types of gas can be ordered through customer service. To change the nozzle, please contact customer service.

• Dimensions of the device (HxWxD mm): 59 x 912 x 520

• Required niche size (HxWxD mm): 45 x 850 x (490 - 502)

• Minimum worktop thickness: 30 mm

• Power cable: 1.5 m

• Total connected load: 13.8 kW

• Gas troughs with a connected load of more than 11 kW must meet additional requirements, e.g. B. controlled room ventilation with a ventilation hood in exhaust mode. These may need to be discussed with the installer.

Accessories included

• Wok attachment ring included

Technical data

• Device type: gas switch recess

• Design: built-in

• Energy source: gas

• Number of cooking zones: 5

• Controls: Sword toggle

• Min. niche dimensions for installation (H x W x D): 45 x 850-852 x 490-502 mm

• Device width: 912 mm

• Dimensions of the device (H x W x D): 59x912x520 mm

• Dimensions of the packed device: 170 x 1110 x 660 mm

• Net weight: 18.2 kg

• Gross weight: 20.6 kg

• Residual heat display: None

• Location of the control: Front

• Main surface material: glass ceramic

• Surface color: Black, aluminum, brushed

• Frame color: Black

• Length of connection cable: 150.0 cm

• EAN number: 4242003925706

• Gas connection value: 13800 W

• Fuse: 3 A

• Voltage: 220-240V

• Frequency: 50; 60Hz
