Novy Up Power Wok 40008 downlight fan with induction hob + wok, black, 87 cm, INCLUDING 5 YEAR manufacturer's guarantee! * (Conditions manufacturer's guarantee)
Special features:
- Direct suction at the source through the centrally placed suction tower
- Manual height adjustment of the suction tower
- Adjustable air guide flap on the plane or directly on the edge of the pot for directed extraction of the vapors
- Suction tower disappears almost invisibly in the hob
- Combination of different hobs possible
- with wok hob
- Surface-mounted and flush-mounted installation possible
Downdraft fan functions:
- Motor integrated
- Number of motors 1
- Exhaust air, recirculated air optional
- Number of power levels 3 + Power
- Running time timer circulating air (min.) / outlet to outside (min.) 10-30 (default setting)
- Saturation display for grease filters
- Saturation indicator/replacement indicator for recirculating air filter
- Adjustable suction
- Suction height tower (cm) 0, 10
- Collection container fixed
- Operation Tower Manual
Functions induction hob:
- Touch operation + slider
- Color of the functions red
- Round glass edge
- Support / Flush
- Black opaque glass
- Number of power levels per zone 9 + Power
- Flex Zones (1×)
- Manual bridge function Flex Zones
- Wok hob
- Lock (child safety) hob
- Timer
- Cooking Timer
Technical information induction hob:
- Cooking zone 1 left front, dimensions (mm) / Power (Boost) W 240 x 200 / 1600 (1850)
- Cooking zone 2 left rear, dimensions (mm) / power (boost) W 240 x 200 / 2100 (3000)
- cooking zone 3 right front, dimensions (mm) / power (boost) W 360 2000 (3200) wok hob
Technical properties:
- 1 integrated motor
- Free-blowing motor power (m³/h) 750
- Motor power exhaust air max. power level (m³/h) (Qboost) 537
- Sound power level exhaust air max. power level (dB(A)) (LWAboost) 64
- Sound power level exhaust air min level (dB(A)) (LWAmin) 55
- Weight of extractor hood / motor housing (kg) 31.6
- Electrical connection value (W) 6900
- Connection voltage of extractor hood 230 V
- Connection voltage of hob 230 V - 1N / 2N
- Energy efficiency class (EEI extractor hood) B
- Annual energy consumption (kWh/year) (AEC extractor hood) 55.9
- Fan efficiency class (FDED extractor hood) C
- Grease filter efficiency class (GFED extractor hood) C
- Device dimensions (W×D×H) 872×520×228
- Outlet opening diameter (mm) 89×222
- Outlet position left rear / left downwards
Included in delivery:
- metal grease filter, dishwasher safe
- mounting material
- mounting instructions
