Novy Up Power 40004 downlight fan with induction hob, black, 87 cm, with 5 year guarantee

Novy Up Power 40004 downlight fan with induction hob, black, 87 cm, with 5 year guarantee

Novy Up Power 40004 downlight fan with induction hob, black, 87 cm, with 5 year guarantee

Novy Up Power 40004 downlight fan with induction hob, black, direct extraction, recirculation air optional, metal grease filter, grease filter saturation indicator, residual heat indicator, flex zones, manual bridge function, child lock, timer, safety switch-off, 87 cm, with 5 year guarantee
Read more
Vendor code: 40004
Energy class: B
Delivery time: 10-12 days
4 004.00€


Add to cart

For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

Novy Up Power 40004 downlight fan with induction hob, black, 87 cm, INCLUDING 5 YEAR manufacturer's guarantee! * (Conditions manufacturer's guarantee)

Special features:

  • Direct suction at the source through the centrally placed suction tower
  • Manual height adjustment of the suction tower
  • Adjustable air guide flap on the plane or directly on the edge of the pot for directed extraction of the vapors
  • Suction tower disappears almost invisibly in the hob
  • Combination of different hobs possible
  • Surface-mounted and flush-mounted installation possible

Downdraft fan functions:

  • Motor integrated
  • Number of motors 1
  • Exhaust air, recirculated air optional
  • Number of power levels 3 + Power
  • Running time timer circulating air (min.) / outlet to outside (min.) 10-30 (default setting)
  • Saturation display for grease filters
  • Saturation indicator/replacement indicator for recirculating air filter
  • Adjustable suction
  • Suction height tower (cm) 0, 10
  • Collection container fixed
  • Operation Tower Manual

Functions induction hob:

  • Touch operation
  • Color of the functions red
  • Round glass edge
  • Support / Flush
  • Black opaque glass
  • Number of power levels per zone 9 + Power
  • Flex Zones (2×)
  • Manual bridge function Flex Zones
  • Lock (child safety) hob
  • Timer
  • Cooking Timer

Technical information induction hob:

  • Cooking zone 1 left front, dimensions (mm) / Power (Boost) W 240 x 200 / 1600 (1850)
  • Cooking zone 2 Left rear, Dimensions (mm) / Power(Boost) W 240 x 200 / 2100 (3000)
  • Cooking zone 3 Right front, Dimensions (mm) / Power(Boost) W 240 x 200 / 1600 (1850)
  • Cooking zone 4 right rear, dimensions (mm) / Power (Boost) W 240 x 200 / 2100 (3000)

Technical characteristics:

  • 1 Integrated motor
  • Free-blowing motor power (m³/h) 750
  • Motor power exhaust air max. power level (m³/h) (Qboost) 537
  • Sound power level exhaust air max. power level (dB(A)) (LWAboost) 64
  • Sound power level exhaust air min level (dB(A)) (LWAmin) 55
  • Weight of extractor hood / motor housing (kg) 27.4
  • Electrical connection value (W) 7400
  • Connection voltage of extractor hood 230 V
  • Connection voltage of hob 230 V - 1N / 2N
  • Energy efficiency class (EEI extractor hood) B
  • Annual energy consumption (kWh/year) (AEC extractor hood) 55.9
  • Fan efficiency class (FDED extractor hood) C
  • Grease filter efficiency class (GFED ​​extractor hood) C
  • Device dimensions (W×D×H) 872×520×228
  • Outlet opening diameter (mm) 89×222
  • Outlet position left rear / left downwards

Included in delivery:

  • metal grease filter, dishwasher safe
  • mounting material
  • mounting instructions

* Information about the manufacturer's warranty


The manufacturer offers a 5-year guarantee throughout Germany on the delivered item Novy Up Power 40004 trough fan. If material or manufacturing defects occur during this period, the manufacturer will provide one of the following services at its discretion under the guarantee:
  • Repair the item Novy Up Power 40004 trough fan, or
  • Exchange it for an equivalent or new item Novy Up Power 40004 trough fan (possibly also a successor model)
  • In the event of a warranty claim, please contact:

    NOVY GmbH
    Frankenring 18
    30855 Langenhagen
    Germany

    Tel. +49 (0)511 / 5420771
    Fax +49 (0)511 / 5420772
    info@novy-dunsthooden.de

    Note:

    Your statutory warranty rights towards us remain unaffected. If the purchased item is defective, you can contact us in any case, regardless of whether the warranty case occurs and whether the warranty is claimed or not.
