For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

Special features:

• Wall hood in a flat design with a housing height of 7.5 cm

• Color: black

• Edge suction

  The rising vapor is sucked off the outer edges of the hood body construction and directed to the grease filter behind it. Due to the high flow speed at the edge of the extractor hood, almost no cooking fumes can escape into the kitchen, even with lower motor settings. There are no turbulences, the drag effect is high and rebound effects play no role. The air does not flow into the kitchen, but directly into the extractor hood. The increase in efficiency resulting from edge extraction enables operation at lower power levels, with less energy consumption and lower noise.

  with high flow speed

• Lighting 2 x 20 watt LED

• Recirculation possible with recirculation set, device then at least 76.5 cm high

• Connection to smaller exhaust systems not possible

• Installation of a wireless window switch for supply air/fan control not possible! Use a version for intermediate insertion (item no. 34.118 or 34.119)

• Pipe extension for exhaust air possible up to a room height of approx. 325 cm

Features:

• Motor: integrated/at a distance (inside)
• Sound-insulated high-performance fan
• Powerful ebm-papst motor
• Lighting 2 x 2 W LED
• Electronic circuit 4 levels
• Exhaust air nozzle: 150 mm round

• Grease filter saturation display
• Recirculation air filter saturation display
• Follow-up time can be switched on in all fan levels

• Concealed metal grease filter, dishwasher safe

Technical information

• Type: wall hood
• Motor: integrated
• Dimensions (WxD): 898 x 520 mm

• Width: 90 cm

• Height (min. - max.) with exhaust air: 71 - 114 cm

• Shaft extension height max.: 146 cm

• Dimensions shaft (WxD): 23.75 x 24.2 cm

• Performance / pressure 1st stage: 248 m³/h / 413 Pa

• Performance / pressure 2nd stage: 329 m³/h / 466 Pa

• Performance / pressure 3rd stage: 423 m³/h / 505 Pa

• Performance / Pressure Intensive: 640 m³/h / 544 Pa

• Noise Sound pressure (sound power) 1st stage: 45 dB(A) re 1 pW / 33 dB(A)

• Noise Sound pressure (sound power) 2nd level: 51 dB(A) re 1 pW / 38 dB(A)

• Noise Sound pressure (sound power) 3rd level: 57 dB(A) re 1 pW / 44 dB(A)

• Noise Sound pressure (sound power) Intensive: 66 dB(A) re 1 pW / 54 dB(A)

• Speed ​​levels: 3 + Power

• Motor exhaust direction: upwards

• Exhaust air connection: 15 cm

• Number of bulbs: 2 x 2 W

• Lighting: LED

• Circuit: Electronic

• Circuit: tip switch

• Number of metal grease filters: 1

• Installation accessories: optional

• Recirculated air: optional

• Connection value max. with external motor: 240 W

• Energy efficiency (class): A

• Annual energy consumption (kWh/year): 49.1

• Fluid dynamic efficiency (class): A

• Lighting Efficiency (Class): A

• Degree of fat separation (class): E

• Consumption in standby (W): 0.3


Included in delivery:

• metal grease filter, dishwasher safe
• mounting material
• mounting instructions

* Information about the manufacturer's warranty
