Flexibility of the cooking zones

• 80 cm: Space for 4 pots or pans

• 2 x Flexzone

• Front left cooking zone: 200 mm, 230 mm, 2.2 kW (maximum power 3.7 kW)

• Rear left cooking zone: 200 mm, 230 mm, 2.2 kW (maximum power 3.7 kW)

• Rear right cooking zone: 200 mm, 230 mm, 2.2 kW (maximum power 3.7 kW)

• Front right cooking zone: 200 mm, 230 mm, 2.2 kW (maximum power 3.7 kW)

Comfort

• Air sensor Automatic Air

• Favorites button

• 17 power levels

• Switch Off Timer

Time saving and efficiency

• Power level for pots

• Power Transfer
• Quick Start and Restart function

Cooking support

• Frying sensor 70° to 220 °C with 11 temperature levels prevents burning thanks to the sensor's automatic temperature control.

• Cooking Assistant

Connectivity

• Home Connect function (WLAN)

• External trigger via favorite button (partner service required)

• Upgradable Device

Theme

• exclusive cooking zone printing
• without frame, for flush installation
• ATTENTION: The Twist Pad Flex® shown is not included in the scope of delivery

Safety

• 2-stage residual heat display each Cooking zone

• Parental Controls

• Wipe protection function
• Main switch

• Automatic safety shutdown

Accessories included

• Clean Air Plus odor filter, telescopic slide element for circulating air included
• included Z861SB2, 90° flat duct elbow vertical black

Extractor hood performance

• Exhaust air performance (according to EN 61591): min. normal level 154 m³/h, max. normal level 500 m³/h, max. boost/intensive level 622 m³/h

• Recirculation air output (according to EN 61591): min. normal level 132 m³/h, max. normal level 499 m³/h, max. boost/intensive level 595 m³/h

• Noise values ​​in exhaust air mode: min. normal level 42 dB re 1 pW, max. normal level 69 dB re 1 pW, max. boost/intensive level 74 dB re 1 pWNoise levels in recirculated air mode:

• min. normal level 41 dB re 1 pW, max. normal level 68 dB re 1 pW, max. boost/intensive level 72 dB re 1 pW

• Grease filter efficiency: 94%

• Average energy consumption: 61.6 kWh/year

• Energy efficiency class: B

• Fan efficiency class: A

• Grease filter efficiency class: B

• Noise min./max. Normal level: 42 dB & 69 dB

• In recirculation mode, 2 x 2 directly integrated powerful Clean Air Plus recirculation filter with optimized odor reduction (e.g. fish smells), anti-pollen function and a filter life of 360 hours during intensive cooking.

• Optimized odor reduction when cooking with complex odor molecule chains (e.g. fish smells).

• Large filter surface with high odor reduction rate

• Anti-Pollen function: The filter retains an extremely high amount of pollen in the air and deactivates the allergens that are retained by the filter.

• Filter life of 360 hours with intensive cooking (cannot be regenerated)

• Very low noise with optimized psychoacoustics

• Easy access and removal from above through the air inlet

• Clean Air Plus replacement filter set Z821VR1

Planning and installation instructions

• Suitable for exhaust air or recirculation air installation in 4 different versions (unguided, partially ducted and fully ducted recirculation or exhaust air). Installation accessories for the unguided circulating air, including four Clean Air Plus odor filters and a telescopic sliding element, are included in the scope of delivery of the hob.

• Various duct accessories are available to complete the fully managed recirculation or for any other individual recirculation planning.

Technical data

• Product name/family: Glass ceramic hob

• Design: built-in

• Energy source: Electric

• Number of cooking zones: 4

• Min niche dimensions for installation (H x W x D): 227 x 796 x 516 mm

• Device width: 792 mm

• Dimensions of the device: 227 x 792 x 512 mm

• Dimensions of the packaged device: 431 x 950 x 672 mm

• Net weight: 24.6 kg

• Gross weight: 31.0 kg

• Residual heat display: Disconnected

• Location of control: Front

• Surface color: Black

• Length of connection cable: 110.0 cm

• EAN number: 4242004277514

• Voltage: 220-240V

• Frequency: 50; 60 Hz
