For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

Flexibility of the cooking zones

• 80 cm: Space for 4 pots or pans

• 2 CombiZone cooking zones: When using larger cookware, two cooking zones are connected to form a larger one.

• Front left cooking zone: 190 mm, 210 mm, 2.5 kW (maximum power 3.7 kW)

• Rear left cooking zone: 190 mm, 210 mm, 2.5 kW (maximum power 3.7 kW)

• Rear right cooking zone: 190 mm, 210 mm, 2.5 kW (maximum power 3.7 kW)

• Front right cooking zone: 190 mm, 210 mm, 2.5 kW (maximum power 3.7 kW)

Ease of use

• Favorite button: Access favorite functions directly with a configurable button.

• 17 power levels: Adjust the heat precisely with 17 power levels (9 main levels and 8 intermediate levels).

• Switch Off Timer: switches off the cooking zone at the end of the set time (e.g. for boiled eggs).

• Alternatively, alarm clock: A signal sounds at the end of the set time (e.g. when cooking pasta).

• The volume of the signal tones can be adjusted to suit personal preferences and needs.

Time savings and efficiency

• Power level for pots: With 50% more power, e.g. B. Bring water to the boil faster than at the highest power level.

• Quick Start function: When switched on, the hob automatically selects the cooking zone on which cookware was placed when it was switched off.

• Restart function: If the hob is switched off unintentionally, all settings will be retained if you switch it on again within 4 seconds.

Cooking support

• 11 frying areas: prevents burning thanks to the automatic temperature control of the sensor.

• Cooking Assistant: Easily find the right temperature setting for a specific dish via the Home Connect app.

Connectivity

• Home Connect function (WLAN): Check whether the hob is switched off even when you are not at home and search for recipes or additional functions in the Home Connect app.

• External trigger via MyButton: Open the intelligent universe from your hob (partner service required).

• Upgradable device (available with connected Home Connect account): Always keep the device up to date with the latest software.

Design

• exclusive cooking zone printing
• Flex Design including design kit Anthracite Gray Z9802PFAY0

• additional design kits can be retrofitted (see accessories)


Safety

• 2-stage residual heat display for each cooking zone: Shows which cooking zones are still hot or warm.

• Child safety lock: Prevents the hob from being activated unintentionally.

• Wipe protection function: Wipe over boiled liquids without unintentionally changing the settings (all touch buttons are blocked for 30 seconds).

• Main switch: Switch off all cooking zones at once.

• Automatic safety switch-off: For safety reasons, the hob switches off automatically after a preset time without interaction (adjustable).

Accessories included

• Clean Air Plus odor filter, telescopic slide element for circulating air included

Extractor hood performance

• Exhaust air performance (according to EN 61591): min. normal level 154 m³/h, max. normal level 500 m³/h, max. boost/intensive level 622 m³/h

• Recirculation air performance (according to EN 61591): min. normal level 117 m³/h, max. normal level 487 m³/h, max. boost/intensive level 595 m³/h

• Noise values ​​for exhaust air operation: min. normal level 42 dB re 1 pW, max. normal level 69 dB re 1 pW, max. boost/intensive level 74 dB re 1 pW

• Noise values ​​in recirculation mode: min. normal level 41 dB re 1 pW, max. normal level 68 dB re 1 pW, max. boost/intensive level 72 dB re 1 pW

• Grease filter efficiency: 94%

• Average energy consumption: 61.6 kWh/year 2)

• Energy efficiency class: B 1)

• Fan efficiency class: A 2)

• Grease filter efficiency class: B 2)

• Noise min./max. Normal level: 42 dB & 69 dB

• For recirculation mode, 2 x 2 directly integrated powerful Clean Air Plus recirculation filters
• Optimized odor reduction when cooking with complex odor molecule chains (e.g. fish smells).

• Large filter surface with high odor reduction rate

• Anti-Pollen function: The filter retains an extremely high amount of pollen in the air and deactivates it
• the allergens that are retained by the filter.

• Filter life of 360 hours with intensive cooking (cannot be regenerated)

• Very low noise with optimized psychoacoustics

• Easy access and removal from above through the air inlet

• Clean Air Plus replacement filter set Z821VR1

Planning and installation instructions

• Suitable for exhaust air or recirculation air installation in 4 different versions (unguided, partially ducted and fully ducted recirculation or exhaust air). Installation accessories for the unguided circulating air, including four Clean Air Plus odor filters and a telescopic sliding element, are included in the scope of delivery of the hob.

• Various duct accessories are available to complete the fully managed recirculation or for any other individual recirculation planning.
• Dimensions of the device (HxWxD mm): 223 x 834 x 527

• Required niche size (HxWxD mm: 223 x 750 x (490 - 500)

Technical data

• Grill function: hob

• Glass ceramic

• Design: built-in

• Heating type: electric hob

• Min . Niche dimensions for installation (H x W x D): 223 x 750-750 x 490-500 mm
  .
• Width: 834 mm
  . Dimensions of the device: 223 x 834 x 527 mm
  . 431 x 950 x 672 mm
  .
• Net weight: 25.4 kg
  .
• Gross weight: 31.8 kg
  .
• Surface color: Black
  .
• length Connection cable: 110.0 cm.
• Sealed hob: No.
• Heaters with booster: All.
• Power of the 2nd cooking zone: 3.6 kW performance with intensive level recirculation mode: 595.0 m³/h

• Max. fan power recirculation mode: 487 m³/h

• Fan performance in intensive exhaust mode: 622 m³/h

• Noise: 69 dB(A) re 1 pW

• Odor filter: No

• Voltage: 220-240/380-415V

• Frequency: 50-60 Hz

• Length of connection cable: 110.0 cm

• Min. niche dimensions for installation (H x W x D): 223 x 750-750 x 490-500 mm

• Dimensions of the device: 223 x 834 x 527 mm

• Dimensions of the packed device: 431 x 950 x 672 mm

• Net weight: 25.4 kg

• Gross weight: 31.8 kg

• Integrated accessories: 1 x telescopic slide element for circulating air, 1 x Clean Air Plus odor filter

• Delay Shut off modes: 30R_12E min

¹) On an EEK scale from: A+++ to D
²) According to EU regulation No. 65/2014
