For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

Operation

• Touch Control


Design

• Design frame in stainless steel

Flexibility of the cooking zones

• 2 CombiZone cooking zones: When using larger cookware, two cooking zones are connected to form a larger one.

• Front left cooking zone: 190 mm, 210 mm, 2.2 kW (maximum power 3.7 kW)

• Rear left cooking zone: 190 mm, 210 mm, 2.2 kW (maximum power 3.7 kW)

• Rear right cooking zone: 190 mm, 210 mm, 2.2 kW (maximum power 3.7 kW)

• Cooking zone at the front right: 190 mm, 210 mm, 2.2 kW (maximum power 3.7 kW)

Comfort

• 17 power levels

• Keep warm function for all cooking zones

• Count Up Timer

• Minute minder

• Power level for pots

• Quick Start function

• Restart function

• Frying sensor with 4 temperature levels

• 2-stage residual heat display for each cooking zone
• Parental Controls

• Wipe protection function

• Main switch

• Automatic safety shutdown

• Energy consumption display

Technical information

• Min. worktop thickness: 16 mm

• Connected load: 7400 W

• Power management function

• Power cable: 110 cm, connection cable enclosed in packaging
• Dimensions of the device (HxWxD mm): 223 x 826 x 546

• Required niche size (HxWxD mm): 223 x 750 x (500 - 500)

Equipment extractor hood

• either exhaust air or recirculated air mode, the device can be used for unguided recirculated air or direct exhaust air without any additional accessories.

• When operating in partially/fully recirculated air or exhaust air, you must order the appropriate set for ≥60 cm or ≥70 cm worktop depth.

• 9 electronically controlled power levels and 2 boost/intensive levels (with automatic reset) thanks to the touch control fan run-on for 30 minutes
• Automatic switching on of the ventilation system when using a cooking zone
• Automatic delayed switch-off after cooking to eliminate residual odors after cooking (in specific ultra-low-noise fan level, 12min (exhaust air), 30min (recirculated air), can be switched off manually)

• Fully manual control possible via touch control

• Blower technology with high-efficiency, low-noise, brushless direct current (BLDC) motor.

• Flow-optimized air flow in the interior

• Easy to remove and clean the grease filter and overflow protection unit:

• Convenient one-handed removal of the unit using a floating glass ceramic handle
• Large, 12-layer stainless steel grease filters for high grease filtration efficiency (94%)
• All parts are easy to clean, dishwasher safe and heat resistant

• A total capacity of 900ml (200ml + 700ml)

• Waterproof ventilation system
• including recirculation set (filter & slider) for unguided recirculation/direct exhaust air
• For partially/fully ducted recirculation or exhaust air, please order as a set, see planning matrix for air ducting
• included incl. Z861SB2 flat duct bend vertical 90° (L-radius)

Performance data extractor hood

• Exhaust air performance (according to EN 61591): min. normal level 154 m³/h, max. normal level 500 m³/h, max. boost/intensive level 622 m³/h

• Circulation capacity (according to EN 61591): min. normal level 150 m³/h, max. normal level 500 m³/h, max. boost/intensive level 615 m³/h

• Noise values ​​for exhaust air operation: min. normal level 42 dB re 1 pW, max. normal level 69 dB re 1 pW, max. boost/intensive level 74 dB re 1 pW

• Noise values ​​in recirculation mode: min. normal level 41 dB re 1 pW, max. normal level 68 dB re 1 pW, max. boost/intensive level 72 dB re 1 pW

• Grease filter efficiency: 94%.

Consumption data extractor hood

• Energy efficiency class: B
• Average energy consumption: 61.6 kWh/year
• Fan efficiency class: A
• Grease filter efficiency class: B
• Noise min./max. Normal level: 42/69 dB
• Planning and installation information: see planning matrix for air flow
