For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

Operation

• Touch Control


Design

• Without frame, for flush installation

• For installation in stone, granite or plastic worktops

• Other worktop materials require a suitability test from the worktop manufacturer

Flexibility of the cooking zones

• 2 CombiZone cooking zones: When using larger cookware, two cooking zones are connected to form a larger one.

• Front left cooking zone: 190 mm, 210 mm, 2.2 kW (maximum power 3.7 kW)

• Rear left cooking zone: 190 mm, 210 mm, 2.2 kW (maximum power 3.7 kW)

• Rear right cooking zone: 190 mm, 210 mm, 2.2 kW (maximum power 3.7 kW)

• Cooking zone at the front right: 190 mm, 210 mm, 2.2 kW (maximum power 3.7 kW)

Comfort

• 17 power levels

• Keep warm function for all cooking zones

• Count Up Timer

• Minute minder

• Power level for pots

• Quick Start function

• Restart function

• Frying sensor with 4 temperature levels

• 2-stage residual heat display for each cooking zone
• Parental Controls

• Wipe protection function

• Main switch

• Automatic safety shutdown

• Energy consumption display

Technical information

• Min. worktop thickness: 16 mm

• Connected load: 7400 W

• Power management function

• Power cable: 110 cm, connection cable enclosed in packaging
• Dimensions of the device (HxWxD mm): 227 x 684 x ​​512

• Required cutout for installation (HxWxD mm): 227 x 689 x 516

Equipment extractor hood

• Choice of exhaust air or recirculation air mode, the device can be used for unguided recirculation air or direct exhaust air without any additional accessories.

• When operating in partially/fully recirculated air or exhaust air, you must order the appropriate set for ≥60 cm or ≥70 cm worktop depth.

• Aesthetically fully integrated, flush extractor design with floating, heat-resistant glass ceramic element for free movement and placement of the cookware.

• Ventilation system with 9 electronically controlled power levels and 2 boost/intensive levels (with automatic reset) via the touch control control panel:

• automatic switching on of the ventilation system when using a cooking zone.

• automatic fan run-on after cooking to eliminate all residual odors after cooking (in a very quiet special fan setting, 12min in exhaust air mode, 30min in recirculation mode, the run-on can be ended manually).

• The manual fan level selection is carried out using the Touch Control control panel.

• Powerful, low-noise fan with energy-efficient BLDC technology.

• High extraction performance with very low noise

• Comfortable and practical removable grease filter and overflow protection unit
• including recirculation set (filter & slider) for unguided recirculation/direct exhaust air
• For partially/fully ducted recirculation or exhaust air, please order as a set, see planning matrix for air ducting
• included incl. Z861SB2 flat duct bend vertical 90° (L-radius)

Performance data extractor hood

• Exhaust air performance (according to EN 61591): min. normal level 154 m³/h, max. normal level 500 m³/h, max. boost/intensive level 622 m³/h

• Circulation capacity (according to EN 61591): min. normal level 150 m³/h, max. normal level 500 m³/h, max. boost/intensive level 615 m³/h

• Noise values ​​for exhaust air operation: min. normal level 42 dB re 1 pW, max. normal level 69 dB re 1 pW, max. boost/intensive level 74 dB re 1 pW

• Noise values ​​in recirculation mode: min. normal level 41 dB re 1 pW, max. normal level 68 dB re 1 pW, max. boost/intensive level 72 dB re 1 pW

• Grease filter efficiency: 94%.

Consumption data extractor hood

• Energy efficiency class: B
• Average energy consumption: 61.6 kWh/year
• Fan efficiency class: A
• Grease filter efficiency class: B
• Noise min./max. Normal level: 42/69 dB
• Planning and installation information: see planning matrix for air flow
