For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

Design

• Flex Design including design kit Anthracite Gray Z91BIE9AY0

• additional design kits can be retrofitted (see accessories)

• Slanted Food Design

• Wall mounting

• Glass pane: black printed

• Optional exhaust air or recirculation mode

• Chimney-free operation possible with recirculated air

• The Clean Air Plus recirculation set (accessory) or the Longlife recirculation set (accessory) is required for recirculation operation.

Most important features

• Efficient Drive motor technology - quiet and energy-efficient motor

• Lighting: 2 pieces, LED, 3 W, with color temperature adjustable

• Softlight: the lighting switches on and off gently.

• Dimming function: the brightness of the lighting can be adjusted.

• Color temperature: 3500 K

• Illuminance: 422 lux

• Boost Position: Intermediate positions of the glass filter cover to better extract particularly strong cooking odors and amounts of steam.

• Extractor hood on the front and bottom

• 3 metal grease filters

Comfort

• Air quality sensor Automatic Air: Automatic sensor-based performance control for best results

• Touch Control

• 3 performance levels and 2 intensive levels

• Automatic reset from intensive to normal level after 6 minutes

• Saturation display for grease and odor filters

• Automatic run-on time: 10 minutes
• Extremely large opening angle for easy access to the filters and easy cleaning.

• The surfaces and materials are smooth and easy to clean.

• Aerodynamically optimized inner frame, easy to clean

• Metal grease filter, dishwasher safe

Output exhaust air

• According to EN 61591 and EN/IEC 60704-2-13, your device can achieve the following values ​​in exhaust mode:

• Performance level 1: Fan performance: 228 m3/h; Noise value: 35 dB(A) re1pW

• Performance level 2: Fan performance: 325 m3/h; Noise value: 43 dB(A) re1pW

• Performance level 3: Fan performance: 41 m3/h; Noise value: 51 dB(A) re1pW

• Intensive level 1: Fan performance: 753 m3/h; Noise value: 65 dB(A) re1pW

• Intensive level 2: Fan performance: 1007 m3/h; Noise value: 70 dB (A) re1pW

• Energy efficiency class: A+ (on an energy efficiency class scale from A+++ to D)

• Average energy consumption: 39.1 kWh/year

• Fan efficiency class: A

• Lighting efficiency class: A

• Grease filter efficiency class: C

Recirculation air performance

• According to EN 61591 and EN/IEC 60704-2-13, your device can achieve the following values ​​in recirculation mode with the Clean Air plus recirculation set for installation with a chimney:

• Performance level 1: Fan performance: 211 m3/h; Noise value: 42 dB(A) re1pW

• Performance level 2: Fan performance: 315 m3/h; Noise value: 51 dB(A) re1pW

• Performance level 3: Fan performance: 435 m3/h; Noise value: 59 dB(A) re1pW

• Intensive level 1: Fan performance: 752 m3/h; Noise value: 72 dB(A) re1pW

• Intensive level 2: Fan performance: 964 m3/h; Noise value: 78 dB (A) re1pW

• According to EN 61591 and EN/IEC 60704-2-13, your device can achieve the following values ​​in recirculation mode with the Clean Air plus recirculation set for chimney-free installation:

• Performance level 1: Fan performance: 214 m3/h; Noise value: 42 dB(A) re1pW

• Performance level 2: Fan performance: 312 m3/h; Noise value: 51 dB(A) re1pW

• Performance level 3: Fan performance: 437 m3/h; Noise value: 60 dB(A) re1pW

• Intensive level 1: Fan performance: 751 m3/h; Noise value: 74 dB(A) re1pW

• Intensive level 2: Fan performance: 944 m3/h; Noise value: 80 dB (A) re1pW


Technical data and sustainability

• Total connected load: 250 W

• Voltage: 220 - 240 V

• Made in Germany: manufactured in a CO2-neutral production facility

• Environmentally friendly packaging

• The most efficient fan technology on the market

• Available odor filter as a regenerable long life filter with a service life of 10 years
• Air quality sensor Automatic Air: Sensor-based performance control for best results with minimal energy consumption.

Planning and installation

• Device dimensions, exhaust air (HxWxD): 855-1098 x 890 x 447 mm

• Device dimensions for circulating air (HxWxD): 892-1185 x 890 x 447 mm

• Dimensions of recirculating air installation, chimneyless (HxWxD): 471 mm x 890 mm x 447 mm

• Simple and weight-reduced installation thanks to the new Easy Installation System

• Exhaust air connection Ø 150 mm

• Length of connection cable: 1.3 m with plug

• Delivery with backflow flap
