For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards
General information
- Choice of exhaust air or recirculation mode
- Chimney-free operation possible with recirculated air
- A recirculation set (special accessory) is required for recirculation operation
- Equipped with black fireplace
- Energy efficiency class: B, on an EEK scale from: A+++ to D
- Average energy consumption: 41.1 kWh/year
- Fan efficiency class: B
- Lighting efficiency class: A
- Grease filter efficiency class: B
- Noise min./max. Normal level: 43/57 dB
- According to EU regulation No. 65/2014
Design:
- Filter cover in glass
- Glass pane: black printed
- Clean-friendly, aerodynamically optimized inner frame
- For wall mounting above hotplates
Komfort
- Home Connect
Control of the device via app; It is also possible to have suitable settings or programs suggested
- Air Fresh interval ventilation
- Touch control operation (3 power levels and 2 intensive levels) with LED display, 3x7 segment
- Intensive levels with automatic reset
- Automatic fan run-on with digital display
- Air sensor
- Silence button
- Edge suction
The rising vapor is sucked off the outer edges of the hood body construction and directed to the grease filter behind it. Due to the high flow speed at the edge of the extractor hood, almost no cooking fumes can escape into the kitchen, even with lower motor settings. There are no turbulences, the drag effect is high and rebound effects play no role. The air does not flow into the kitchen, but directly into the extractor hood. The increase in efficiency resulting from edge extraction enables operation at lower power levels, with less energy consumption and lower noise.
- 2 suction areas: front and bottom
- 2 single-flow standing. BLDC Motor
- Power Boost position
- Metal grease filter, dishwasher safe
- Saturation display for grease and odor filters
- Ambient Light
- Dimming function
- Soft Light
The dim light emitted from the Soft Light keypad allows you to see the speed level of the hood at a glance.
- Fully automatic extractor hood
- Remote start and remote monitoring for networking household appliances and operation via smartphone or tablet (only in countries where Home Connect service is available)
- The Home Connect functionality can be expanded as desired by integrating numerous applications from external cooperation partners (partnering).
- Voice control possible via common voice assistants
- Adjustable color temperature (2,700 K - 5,000 K) for adaptation to the room lighting available via Home Connect
Technical information
- Device dimensions, exhaust air (HxWxD): 981-1251 x 890 x 362 mm
- Device dimensions for circulating air with chimney (HxWxD): 1041-1311 x 890 x 362 mm
- Device dimensions for recirculating air with Clean Air recirculating air set (HxWxD): 1171 x 890 x 362 mm - installation on external duct
- 1241-1511 x 890 x 362 mm - mounting on inner channel
- Device dimensions for circulating air without chimney (HxWxD): 512 mm x 890 x 362 mm
- Exhaust air output according to EN 61591: max. normal operation 394 m³/h, intensive level 717 m³/h
- Noise values according to EN 60704-2-13 for exhaust air operation: Max. normal level: 57 dB(A) re 1 pW, intensive level: 70 dB(A) re 1 pW
- When using the separately available Clean Air Plus recirculation set (special accessory), your device achieves the following values in recirculation mode:
- Recirculation level: max. normal operation: 311 m³/h, intensive level: 578 m³/h
- Noise values in recirculation mode: max. normal level: 60 dB(A) re 1 pW, intensive level: 74 dB(A) re 1 pW
- Workplace lighting with 2 x 3 W LED modules
- Illuminance: 360 lux, color temperature: 3500 K
- Exhaust air connection Ø 150 mm (Ø 120 mm included)
- Connection cable 1.3 m with plug
- Total connected load: 150 W
- with backflow flap
- Operation via gas hob not permitted
