For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues so that they can then be wiped off much more easily
homeier all in one Downair Mistral, table hood, 65cm, exhaust air, 1409941, With 5-year guarantee, INCLUDING 5-YEAR manufacturer's guarantee! * ( Conditions Manufacturer's Warranty )
The kitchen is the central meeting place for family and friends. Clean air free of cooking fumes plays an important role in well-being. Homeier supplies the technically high-quality equipment for this. The company in Regensburg has been developing and producing extractor hoods in the highest quality segment for more than 30 years. Numerous product innovations in combination with the processing of fine materials demonstrate a high level of engineering art. Whether as a unique individual piece or as an integrative design element of a technically and functionally equipped kitchen, Homeier extractor hoods offer more than just a pure ventilation unit. Perfect products that can also be individually adapted to the needs of the user are another specialty of the Bavarian company. If you are looking for a tailor-made solution to match the exclusive kitchen interior or the rest of the apartment ambience, you will find the experienced partner for system ventilation at Homeier-Atelier. If you require information in advance for your individual planning requirements, please contact us without obligation. The ascasa team will be happy to provide you with advice and assistance.
Complete freedom when cooking
- 2-motor base fan for powerful extraction
- Two suction openings with a simple hand opening mechanism
- Compact fan housing that can be stored under the cabinet to save space, from a base height of 100 mm and thus leaves space in the cupboard for pots and pans
- Two cleaning stages with a combination of centrifugal force and
- depth filtration ensure top values for fat separation
- Filter cassettes can be completely removed and cleaned in the dishwasher
- Automatic and semi-automatic fan control as well as automatic run-on
Advantages of the homeier induction hob
- Large, fully usable hob (65 x 50.5 cm) with flexible cooking zone design
- Intuitive touch control panel: easy selection of the desired cooking zones, power levels and other functions
- Bridge function: switches Cooking zones together to form a continuous surface - ideal for large, elongated pots and pans
- Timer for each zone: switches the selected cooking surface on or off
- Energy-saving automatic pre-cooking system: pre-cooking times in seconds at maximum temperatures
Technical information:
- Energy efficiency class: A
- Sound power level 9: 73 db
- Power levels: 9+P
- power consumption fan: 2x 170W
- Output level 9: 550 m³/h
- Free-blowing fan performance: 2 x 650 m³/h
- Pipe connection flat duct: 2.22 cm x 0.89 cm
- Grease separation class: B
- Total connected load: 7.7 kW
- Energy consumption hob 179.4 Wh/kg
- Number of cooking zones: 4
- Net weight: 30 kg
- Custom-made depending on the hob (from 572 to 918 mm) plus 202 mm down-air elements
- Not suitable for gas hobs
Efficient fat separation - clean kitchen air
The latest innovation in the hob extraction of the homeier DOWNAIR MISTRAL products is equipped with two cleaning levels. This ensures ruthless effectiveness in air purification with a combination of centrifugal force (1), in which grease, oil and dirt collect and are deposited on an easy-to-clean surface, and depth filtration (2), i.e. grease, oil and dirt collect in the Inside a grease filter, maximum hygiene
is guaranteed in your kitchen.
With the homeier DOWNAIR MISTRAL, the extraction openings are deliberately placed on the side so that the cooking surface can be used completely without disruptive transitions. The two ventilation flaps can be opened separately, adapt optimally to your cooking behavior and ensure the best possible performance in every situation.
Two more plus points: The intuitive real glass control panel reacts even with wet fingers. Simply choose the right one from the 4 power levels. With the optional ECOSWITCH function (depending on the model), which allows you to switch between recirculation and exhaust air mode, you can decide which operating mode is best for your home depending on the weather conditions.
homeier ECOSWITCH
- Combination of exhaust air or recirculating air
- In recirculating air mode, the air sucked in is cleaned of fats and cooking odors and returned to the room via the built-in filters
- Exhaust air mode returns the air cleaned of fats Air to the outside. This operating mode is particularly efficient for intensive frying
- With homeier ECOSWITCH you enjoy the freedom to switch between circulating air or exhaust air mode as needed, depending on the weather situation, the cooking plan and the local conditions
- Maximum comfort meets ecological most sensible solution.
* Manufacturer warranty details
The manufacturer grants a 5-year guarantee throughout Germany on the delivered item homeier all in one Downair Mistral, table hood, exhaust air, made-to-measure, 1409941. If material or manufacturing defects occur during this period, the manufacturer grants one of the following services of its choice as part of the guarantee :
Repair of the item homeier all in one Downair Mistral, table hood, exhaust air, 1409941 or
Exchange for an equivalent or new item homeier all in one Downair Mistral, table hood, exhaust air, 1409941 (possibly also a successor model)
In the event of a warranty claim, please contact:
berbel Ablufttechnik GmbH
Factory customer service
Sandkampstrasse 100
48432 Rheine
Tel: +49 (0) 5971 / 80809-660
Email: service@berbel.de
Note:
Your statutory warranty rights towards us remain unaffected. If the purchased item is defective, you can contact us in any case, regardless of whether the warranty case occurs and whether the warranty is claimed or not.
