For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking chamber and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

• LED lighting: Economical and long-lasting - the entire hob in view (with light efficiency class A).
• 3-level fan performance: Always fresh air thanks to the powerful motor - adjustable in 3 levels.
• Made in Germany: Quality made in Germany.
• Long-lasting metal grease filter: Quick and easy cleaning possible, dishwasher safe.

Design

• Box Design

• Wall mounting

• For exhaust air or recirculation mode

Most important features

• Energy-efficient capacitor motor

• 2 x LED 1.5 W

• Color temperature: 3500 K

• Illuminance: 293 lux

• 2 metal grease filters, dishwasher-safe
• Push buttons
• Fan power 3 levels
• The surfaces and materials are smooth and easy to clean.
• Long-lasting metal grease filter, dishwasher-safe
• Coated surface to reduce fingerprints

Exhaust mode

• According to EN 61591 and EN/IEC 60704-2-13, the device can achieve the following values ​​in exhaust mode:

  • Performance level 1: Fan performance 361 m3/h; Noise value 57 dB(A) re1pW

  • Performance level 2: Fan performance 469 m3/h; Noise value 63 dB(A) re1pW

  • Performance level 3: Fan performance 594 m3/h; Noise value 67 dB (A) re1pW

• Energy efficiency class: B (on an energy efficiency class scale from A+++ to D)

• Average energy consumption: 72 kWh/year*

• Fan efficiency class: B*

• Lighting efficiency class: A*

• Grease filter efficiency class: B*

Recirculation mode

• A Long-Life Clean Air recirculation set (special accessory) is required for recirculation mode

• The Long-Life Clean Air odor filter absorbs intense odors such as fish and pollen. The lifespan can be extended up to 4 times by refreshing the filter in the oven.
• According to EN 61591 and EN/IEC 60704-2-13, the device can be used in recirculation mode with the Long-Life Clean Air recirculation set (available as a special accessory). achieve the following values:

  • Performance level 1: Fan performance 360 ​​m3/h; Noise value 60 dB(A) re1pW

  • Performance level 2: Fan performance 477 m3/h; Noise value 67 dB(A) re1pW

  • Performance level 3: Fan performance 569 m3/h; Noise value 71 dB (A) re1pW

Technical data and sustainability

• Consumption information:

  • Total connected load: 200 W

  • Voltage: 220 - 240 V

• Sustainability:

  • Made in Germany: manufactured in a CO2-neutral production facility

  • Environmentally friendly packaging

  • Available Long-Life Clean Air odor filter with up to 4 times longer service life

Information on planning and installation

• Less installation effort thanks to the simple assembly system.
• Device dimensions for exhaust air (HxWxD): 635-895 x 898 x 500 mm
• Device dimensions for circulating air (HxWxD): 803-943 x 898 x 500 mm
• Exhaust air outlet: Ø 150 mm
• Length of connection cable: 1.3 m with Plug

Technical data

• Color of the fireplace: metal look
• Design: wall mounting
• Length of connection cable: 130 cm
• Device height: 60 mm
• Minimum distance to the electric hob: 550 mm
• Minimum distance to the gas hob: 650 mm
• Net weight: 10.8 kg
• Control: Mechanical
• Number of power levels: 3
• Max. fan power - exhaust air mode: 594 m³/h
• Max. fan power - recirculation mode: 569 m³/h
• Max. air volume: 594 m³/h
• Number of lamps (pcs): 2
• Noise level: 67 dB(A) right 1pW
• Diameter of the exhaust air nozzle: 150 mm
• Material of the grease filter: metal grease filter, washable
• EAN number: 4242004287841
• Connected load: 200 W
• Voltage: 220-240 V
• Frequency: 50 Hz
• Plug type: Schuko/Gardy.with earthing
• Type of installation: Wall mounting
