For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking chamber and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

• 3-stage fan performance: Always fresh air - adjustable in 3 stages with a slide switch.
• LED lighting: Evenly bright lighting and economical with 1 x 4 W LED module

Performance and consumption

• Energy efficiency class: D (on an energy efficiency class scale from A+++ to D)

• Average energy consumption: 69.3 kWh/year*

• Fan efficiency class: E*

• Lighting efficiency class: E*

• Grease filter efficiency class: D*

Features and comfort

• For installation under a wall cabinet or on the wall

• Pivoting vapor deflector made of glass

• For exhaust air or recirculation air operation

• A standard activated carbon filter is required for recirculation mode (special accessory)

• Fan power can be adjusted to 3 levels using
• Slide switch

• Even, bright lighting with 1 x 1.5 W LED module

• Illuminance: 45 lux

• Color temperature: 3000 K

• Fleece filter

Accessories

• Exhaust air connection Ø 120 mm (Ø 100 mm included)

• Special accessories:- <200065val>

Technical data and dimensions

• Device dimensions (HxWxD): 150 x 600 x 482 mm

• Device dimensions, exhaust air (HxWxD): 150-150 x 600 x 482 mm

• Device dimensions for circulating air (HxWxD): 150-150 x 600 x 482 mm

• Total connected load: 119 W - Voltage: 220 - 240 V

Operating mode and performance

• Max. delivery rate: 250 m3/h

• Noise min./max. Normal level: 53/68 dB

• Fan performance according to EN 61591: in exhaust mode max.250m³/h, in recirculation mode max.80m³/h

• Noise values ​​according to EN 60704-3 and EN 60704-2-13 max.

• Normal level:- Exhaust air mode:68 dB(A) re 1 pW (54dB(A) re 20 µPa sound pressure)

• Recirculation mode:77 dB(A) re 1 pW (63 dB(A) re 20 µPa sound pressure)

Technical data:

• Type: fan module/intermediate/substructure hood
• Length of connection cable: 145.0 cm
• Minimum distance to the electric hob: 650 mm
• Minimum distance to the gas hob: 650 mm
• Net weight: 6.8 kg
• Control: mechanical
• Number of power levels: 3
• Max. fan output-exhaust air mode: 250 m³/h
• Max. fan output-recirculation mode: 80 m³/h
• Max. air volume: 250 m³/h
• Number of lamps (pcs): 1
• Noise level: 68 dB(A) re 1pW
• Diameter of the exhaust air nozzle: 100 / 120 mm
• Material of the grease filter: Non-washable synthetic
• EAN number: 4242004237914
  .
