For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking chamber and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

• FlameSelect: always exactly the right flame strength - with nine predefined power levels.

• Dishwasher safe pot supports : cleaning the hob has never been easier.

• Easy to clean: removable knobs and dishwasher-safe pot supports make cleaning pleasant.
• Dishwasher-safe pot supports: make cleaning your gas hob even easier.

• Smart Hood Automatic: a suitable extractor hood automatically regulates its performance while cooking.

• Touch Control: Effortlessly control cooking time and extractor functions.

Burner and performance

• 4 gas hobs, gradually adjustable

• Front left: normal burner up to 1.75 kW (depending on the type of gas)

• Rear left: Economy burner up to 1.75 kW (depending on the type of gas)

• Rear right: Power burner up to 3 kW (depending on the type of gas)

• Front right: Economy burner up to 1 kW (depending on the type of gas)

Cleaning

• Removable sword toggles: simplifies cleaning between the toggles.

• Dishwasher-safe pot supports: easy to clean in the dishwasher.

• Semi-continuous cast iron pot supports: low weight and compact shape with high stability thanks to the continuous surface.

Ease of use

• FlameSelect: precisely adjust the flame in nine defined levels.
• TopControl digital display: shows the selected power level and residual heat

• Control knob, front: easily accessible and operable knobs in the front area for effortless turning
• 1-hand ignition: to ignite the flame, simply press and turn the knob.

• Alarm clock: an alarm sounds at the end of the set time (e.g. for pasta).

Design

• Tempered glass surface, black
• Frame: front facet
• Semi-continuous cast iron pot holder

• Full metal rotary selector illuminated

Safety

• Thermoelectric ignition safety device: prevents further gas flow when the flame goes out
• 4-fold residual heat indicator: shows which burner parts and pan supports are still hot.

Networking

• Home Connect

  Control of the device via app; It is also possible to have suitable settings or programs suggested

  : check whether the hob is switched off while on the go and use many other functions in the Home Connect app.

• Hob-based hood control (with matching extractor hood): automatically activates the extractor hood when cooking, thanks to the WiFi connection between the hob and extractor hood.

• Smart Hood Automatic: the extractor hood automatically adjusts the fan power to the hob settings (with a suitable extractor hood and a connected Home Connect account).

• The volume of the Touch Control can be adjusted in the Home Connect app depending on your preference.


Installation

• Can be used for:

  • Natural gas L/LL G25/20 mbar (DE)

  • Natural gas H/E 20 mbar, E+ 20/25 mbar

  • Natural gas H 25 mbar (HU)

  • Natural gas L 25 mbar (NL)

  • Liquefied gas G30, 31 28-30/37 mbar
  • Liquefied gas G30 37 mbar (PL)

  • Liquefied gas 50 mbar

  • Preset to natural gas (20 mbar)

• Nozzle set for liquid gas nozzles (28-30/37 mbar) included. Nozzles for all other types of gas can be ordered through customer service. To change the nozzle, please contact customer service.

• Dimensions of the device (HxWxD mm): 54 x 590 x 520

• Required niche dimensions (HxWxD mm): 45 x 560 x (480 - 490)

• Minimum worktop thickness: 20 mm

• Power cable: 1 m

• Total connected load: 7.5 kW

Technical data

• Product name/family: Gas switch recess

• Design: built-in

• Energy source: gas

• Number of cooking zones: 4

• Controls: Sword lever
• Min niche dimensions for installation (H x W x D): 45 x 560 x (480 490) mm

• Device width: 590 mm

• Dimensions of the device: 45 x 590 x 520 mm

• Net weight: 16.9 kg

• Residual heat display: separated
• Location of control: front
• Main surface material: tempered glass
• Surface color: Black
• Length of connection cable: 100 cm

• EAN number: 4242005440887
• Gas connection value: 7500 W
• Fuse: 3 A
• Voltage: 220-240 V

• Frequency: 50; 60 Hz
