For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking chamber and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards
Bosch HND411LW62, SET built-in stove HEA513BW2 + electric hob NKN645GA2E, with 5-year guarantee!
Description oven
Bosch HEA513BW2 , built-in oven, series 4, 60 x 60 cm, white, EEK: A, with 5 year guarantee!
The built-in stove with 3D hot air
Ensures even and efficient heat distribution. This not only allows you to bake or cook on several levels at the same time, it also reduces the baking and cooking time
: this means you can achieve perfect baking and roasting results on several levels at the same time.- Red LED display control: easy to use thanks to the time functions.
- Retractable toggle: for an easy-to-clean front and an elegant design.
Oven type and type of heating
- Built-in oven with 5 heating types: 3D hot air, top/bottom heat, circulating air grill, large area grill, hot air gentle
The fan distributes the heat evenly throughout the entire cooking space, which helps to save energy. When baking on one level - e.g. B. small pastries, sheet cakes or sponge cakes - no preheating is required.
- Temperature control from 50 °C - 275 °C
- Cooking chamber volume: 71 l
Design
- Round control knobs
- Oven with GranitEmail
Cleaning
- Full glass interior door
Comfort
- Operation with LED display
- Electronic clock
- Optical heating control
- Autostart
- Aluminum oven handle
- Rapid heating
- Halogen interior lighting
- Cooling fan
Accessory rack / pull-out system:
- 5 shelf levels
- Extension can be retrofitted
Accessories included
- 1 x combination grate
- 1x universal pan
Environment and safety
- Child safety lock
Technical information:
- Only for combination with a conventional glass ceramic hob.
- Rated voltage: 220 - 240 V
- Total electrical connection value: 11.2 kW
- Energy efficiency class (according to EU No. 65/2014): A (on an energy efficiency class scale from A+++ to D)
- Energy consumption per cycle in conventional mode: 0.97 kWh
- Energy consumption per cycle in recirculation mode: 0.81 kWh
- Number of cooking chambers: 1 Heat source: electric Interior volume: 71 l
- Device dimensions (HxWxD): 595 x 594 x 548mm
- Niche dimensions (HxWxD): 604 mm x 560 mm x 550 mm
- “Observe dimensions and installation instructions for this device according to the technical drawing”
- We recommend that you choose complementary products within the Series 4 product range to ensure the best possible installation situation for your built-in devices.
Description of hob
Bosch NKN645GA2E, stove-controlled electric hob, series 4, with frame, 60 cm , black, with 5 year guarantee!
The electric hob made of glass ceramic: makes cooking and cleaning particularly easy.
- Control panel on the stove: Easy to operate the hob using the stove's controls.
- roasting zone: extra switchable cooking zone for large roasting dishes such as roasters and fish pots.
- The 21 cm cooking zone: expandable cooking zone.
- All-round frame: The flat, all-round stainless steel frame is ideal for fitting into an existing worktop cutout.
Flexibility of the cooking zones
- 60 cm: Space for 4 pots or pans
- Roasting zone: Extra switchable cooking zone for large roasting dishes
- Dual-circuit cooking zone: Use normal or larger cookware for the expandable cooking zone.
- Front left cooking zone: 180 mm, 2 kW
- Rear left cooking zone: 170 mm, 265 mm, 1.6 kW
- Rear right cooking zone: 145 mm, 1.2 kW
- Front right cooking zone: 145 mm, 210 mm, 1 kW
Ease of use
- This hob can only be operated in combination with a suitable built-in stove (HE): Control the power using the knobs on the stove and you see the set power levels on the hob.
Design
- all-round stainless steel frame, lying on
Safety
- 4-fold residual heat display: shows which cooking zones are still hot.
Installation
- Dimensions of the device (HxWxD mm): 43 x 583 x 513
- Required niche size (HxWxD mm): 43 x 560 x (490 - 500)
- Minimum worktop thickness: 16 mm
- Total connected load: 7800 W
- Power cable: 86 cm, connected to connection strip
Technical data
- Product name/family: Glass ceramic hob
- Design: built-in
- Energy source: Electric
- Number of cooking zones: 4
- Min niche dimensions for installation (H x W x D): 43 x 560 x (490 - 500) mm
- Device width: 583 mm
- Dimensions of the device: 43 x 583 x 513 mm
- Dimensions of the packaged device: 100 x 750 x 590 mm
- Net weight: 7.5 kg
- Gross weight: 8.3 kg
- Residual heat display: Disconnected
- Location of the control: combined with built-in ovens/stoves
- Main surface material: glass ceramic
- Surface color: black, stainless steel
- Frame color: stainless steel
- Length of connection cable: 86 cm
- EAN number: 4242005283132
- Voltage: 220-240V
- Frequency: 50; 60 H
