For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking chamber and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards
Bosch HND271AS63, SET built-in stove HEA171BS2 + electric hob NKN645GA2E, with 5-year guarantee!
Description oven
Bosch HEA171BS2, built-in oven, series 2, 60 x 60 cm, stainless steel, EEK: A, with 5 year guarantee!
The built-in stove with AutoPilot: automatically prepares your food perfectly.
- AutoPilot 10: every dish turns out perfectly thanks to 10 preset automatic programs.
- Pyrolysis
Heating the oven up to 500 °C. Any food residue is burned. This process takes 1-3 hours. After pyrolysis, the ash of the burned dirt remains, which can simply be wiped out of the oven with a damp cloth
-Self-cleaning: Cleans the oven automatically. All you have to do is remove the ashes.
- Cleaning support: reduces cleaning effort.
- Gentle hot air
The fan distributes the heat evenly throughout the entire cooking space, which helps to save energy. When baking on one level - e.g. B. small pastries, sheet cakes or sponge cakes - no preheating is required.
: saves energy when baking and frying.
- 3D hot air: even heat for perfect results on up to three levels.
Oven type and heating type
- Temperature control from 30 °C - 275 °C
- Cooking chamber volume: 71 l
Design
- Round control knobs
- TouchControl operation
- Oven with GranitEmail
Cleaning
- Self-cleaning technology (pyrolysis)
- Cleaning support (program) Cleaning aid
- Full glass interior door
Comfort
- LED TouchControl (red/white)
- Electronic clock
- Optical heating control
- Temperature suggestion AutoPilot
- AutoPilot 10 programs
- Aluminum oven handle
- AutoPilot: With the automatic programs, preparation is always successful. Simply select the dish and set the weight.
- Rapid heating
- Oven lighting can be switched off, halogen interior lighting
- Cooling fan
Accessory rack / pull-out system:
- 5 shelf levels
- Extension can be retrofitted
Accessories included
- 1 x combination grate
- 1x universal pan
Environment and safety
- Very low door temperature
- Low door temperature during pyrolytic cleaning
- Parental Controls
- Door locking during pyrolysis operation Safety switch-off Start button
Technical information:
- Only for combination with a conventional glass ceramic hob.
- Rated voltage: 220 - 240 V
- Total electrical connection value: 11.4 kW
- Energy efficiency class (according to EU No. 65/2014): A (on an energy efficiency class scale from A+++ to D)
- Energy consumption per cycle in conventional mode: 0.99 kWh
- Energy consumption per cycle in recirculation mode: 0.81 kWh
- Number of cooking chambers: 1 Heat source: electric Interior volume: 71 l
- Device dimensions (HxWxD): 595 x 594 x 548mm
- Niche dimensions (HxWxD): 604 mm x 560 mm x 550 mm
- Observe dimensions and installation instructions for this device according to the technical drawing!
Description of hob
Bosch NKN645GA2E, stove-controlled electric hob, series 4, with frame, 60 cm , black, with 5 year guarantee!
The electric hob made of glass ceramic: makes cooking and cleaning particularly easy.
- Control panel on the stove: Easy to operate the hob using the stove's controls.
- roasting zone: extra switchable cooking zone for large roasting dishes such as roasters and fish pots.
- The 21 cm cooking zone: expandable cooking zone.
- All-round frame: The flat, all-round stainless steel frame is ideal for fitting into an existing worktop cutout.
Flexibility of the cooking zones
- 60 cm: Space for 4 pots or pans
- Roasting zone: Extra switchable cooking zone for large roasting dishes
- Dual-circuit cooking zone: Use normal or larger cookware for the expandable cooking zone.
- Front left cooking zone: 180 mm, 2 kW
- Rear left cooking zone: 170 mm, 265 mm, 1.6 kW
- Rear right cooking zone: 145 mm, 1.2 kW
- Front right cooking zone: 145 mm, 210 mm, 1 kW
Ease of use
- This hob can only be operated in combination with a suitable built-in stove (HE): Control the power using the knobs on the stove and you see the set power levels on the hob.
Design
- all-round stainless steel frame, lying on
Safety
- 4-fold residual heat display: shows which cooking zones are still hot.
Installation
- Dimensions of the device (HxWxD mm): 43 x 583 x 513
- Required niche size (HxWxD mm): 43 x 560 x (490 - 500)
- Minimum worktop thickness: 16 mm
- Total connected load: 7800 W
- Power cable: 86 cm, connected to connection strip
Technical data
- Product name/family: Glass ceramic hob
- Design: built-in
- Energy source: Electric
- Number of cooking zones: 4
- Min niche dimensions for installation (H x W x D): 43 x 560 x (490 - 500) mm
- Device width: 583 mm
- Dimensions of the device: 43 x 583 x 513 mm
- Dimensions of the packaged device: 100 x 750 x 590 mm
- Net weight: 7.5 kg
- Gross weight: 8.3 kg
- Residual heat display: Disconnected
- Location of the control: combined with built-in ovens/stoves
- Main surface material: glass ceramic
- Surface color: black, stainless steel
- Frame color: stainless steel
- Length of connection cable: 86 cm
- EAN number: 4242005283132
- Voltage: 220-240V
- Frequency: 50; 60 H
