For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking chamber and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues so that they can then be wiped off much more easily

• Quiet motor: Enjoy a quiet cooking experience with maximum suction power and low noise level.

• Touch Select Basic: quick selection of settings via touch operation.

• Filter saturation: automatic reminders to clean and replace the filters

• Easy to clean interior: The large opening angle and smooth surface enable quick cleaning and easy filter replacement.

Design

• Slanted Food Design

• Wall mounting

• Glass pane: black printed

• Optional exhaust air or recirculation mode
• A standard recirculation set (special accessory) is required for recirculation mode

Most important features

• Capacitor Motor

• Workplace lighting with 2 x 3 W power LED modules

• Color temperature: 4000 K

• Illuminance: 127 lux

• 1 metal grease filter

Comfort functions

• Electronic control via DirectSelect operation, backlit

• 3 performance levels and 1 intensive level

• Automatic reset from intensive to normal level after 5 minutes

• Saturation display for grease and odor filters

Comfort during cleaning

• The surfaces and materials are smooth and easy to clean.

• Metal grease filter, dishwasher safe

Output exhaust air

• According to EN 61591 and EN/IEC 60704-2-13, your device can achieve the following values ​​in exhaust mode:

• Performance level 1: Fan performance: 220 m3/h; Noise value 46 dB(A) re1pW

• Performance level 2: Fan performance: 315 m3/h; Noise value 53 dB (A) re1pW

• Performance level 3: Fan performance: 430 m3/h; Noise value 60 dB (A) re1pW

• Intensive level 1: Fan performance: 550 m3/h; Noise value 65 dB (A) re1pW

• Energy efficiency class: A (on an energy efficiency class scale from A+++ to D)

• Average energy consumption: 43.8 kWh/year*

• Fan efficiency class: A*

• Lighting efficiency class: A*

• Grease filter efficiency class: E*

Recirculation air performance

• According to EN 61591 and EN/IEC 60704-2-13, your device can achieve the following values ​​in recirculation mode with the standard recirculation set (available as an optional accessory):

• Performance level 1: Fan performance 215 m3/h; Noise value 51 dB(A) re1pW

• Performance level 2: Fan performance 300 m3/h; Noise value 61 dB(A) re1pW

• Performance level 3: Fan performance 445 m3/h ; Noise value 69 dB(A) re1pW

• Intensive level 1: fan performance 550 m3/h; Noise value 72 dB (A) re1pW

Technical data and sustainability

• Consumption information:

• Voltage: 220 - 240 V

• Total connected load: 223 W

Information on planning and installation

• Device dimensions, exhaust air (HxWxD): 690-900 x 790 x 325 mm

• Device dimensions for circulating air (HxWxD): 720-975 x 790 x 325 mm

• Exhaust air connection Ø 150 mm

• Length of connection cable: 1.5 m with plug

• Delivery with backflow flap

Technical data

• Type: wall mounting

• Length of connection cable: 150.0 cm

• Device height: 325 mm

• Minimum distance to the electric hob: 450 mm

• Minimum distance to the gas hob: 650 mm

• Net weight: 11.4 kg

• Control: electronic

• Max. fan output exhaust air: 430 m³/h

• Fan performance in intensive level recirculation mode: 550.0 m³/h

• Max. fan output for circulating air: 445 m³/h

• Fan performance in intensive exhaust mode: 550 m³/h

• Number of lamps (pcs): 2

• Sound power: 60 dB(A) re 1 pW

• Diameter of the exhaust air connection: 150 mm
• Grease filter material: washable aluminum
• EAN number: 4242005466610
• Connection value: 223 W

• Fuse: 4 A

• Voltage: 220-240V

• Frequency: 50 Hz

• Plug type: Schuko/Gardy with grounding

• Device type: Wall mounting

* According to EU regulation No. 65/2014
