For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking chamber and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues so that they can then be wiped off much more easily

• Button control: simple and convenient adjustment of your extractor hood.
• Dual filter system: efficient and long-lasting air and odor filtration.

• Metal look surface: elegant and polished design for an upscale kitchen atmosphere.

• LED lighting: Bright, energy-saving and reliable lighting when cooking.

Design

• Box Design

• Wall mounting

• Choice of exhaust air or recirculation mode

Most important features and comfort

• Energy-efficient capacitor motor

• 2 x LED 1.5 W

• Color temperature: 3500 K

• Illuminance: 265 lux

• Surfaces and materials are smooth and easy to clean.

• Metal grease filter, dishwasher safe

• Coated surface to reduce fingerprints
• Push buttons

• 3 power levels

Exhaust air mode

• According to EN 61591 and EN/IEC 60704-2-13, the device can achieve the following values ​​in exhaust air mode:

  • Performance level 1: Fan performance 361 m3/h; Noise value 57 dB(A) re1pW

  • Performance level 2: Fan performance 469 m3/h; Noise value 63 dB(A) re1pW

  • Performance level 3: Fan performance 594 m3/h; Noise value 67 dB (A) re1pW

• Energy efficiency class: B (on an energy efficiency class scale from A+++ to D)

• Average energy consumption: 72 kWh/year*

• Fan efficiency class: B*

• Lighting efficiency class: A*

• Grease filter efficiency class: B*

Recirculation mode

• A Long-Life Clean Air recirculation set (special accessory) is required for recirculation mode - The Long-Life Clean Air odor filter absorbs intense odors, such as: B. fish, as well as pollen. The lifespan can be extended up to 4 times by refreshing the filter in the oven
• According to EN 61591 and EN/IEC 60704-2-13, the device can achieve the following values ​​in recirculation mode with the Long-Life Clean Air recirculation set (available as a special accessory):

  • Performance level 1: Fan performance 360 ​​m3/h; Noise value 60 dB(A) re1pW

  • Performance level 2: Fan performance 477 m3/h; Noise value 67 dB(A) re1pW

  • Performance level 3: Fan performance 569 m3/h; Noise value 71 dB (A) re1pW

Technical data and sustainability

• Consumption information:

  • Total connected load: 200 W

  • Voltage: 220 - 240 V
• Sustainability:

  • Made in Germany: manufactured in a CO2-neutral production facility

  • Environmentally friendly packaging

  • Available Long-Life Clean Air odor filter with up to 4 times longer lifespan

Information on planning and installation:

• Lower installation effort thanks to the simple assembly system

• Device dimensions, exhaust air (HxWxD): 635-895 x 898 x 500 mm

• Device dimensions for circulating air (HxWxD): 803-943 x 898 x 500 mm

• Exhaust air outlet: Ø 150 mm

• Length of connection cable: 1.3 m with plug

Technical data

• Type: wall mounting
• Length of connection cable: 130.0 cm

• Device height: 60 mm

• Minimum distance to the electric hob: 550 mm

• Minimum distance to the gas hob: 650 mm

• Net weight: 10.8 kg

• Control: mechanical
• Fan performance at the highest normal level, exhaust air:: 594 m³/h

• Fan performance at the highest normal level circulating air:: 569 m³/h

• Max. air volume: 594 m³/h

• Number of lamps (pcs): 2
• Sound power: 675 dB(A) re 1 pW

• Diameter of the exhaust air connection: 150 mm
• Grease filter material: metal grease filter, washable

• EAN number: 4242005530458
• Connected load: 200 W

• Voltage: 220-240V

• Frequency: 50 Hz

• Plug type: Schuko/Gardy with grounding

• Device type: Wall mounting

* According to EU regulation No. 65/2014
