For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking space and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

• LED lighting: The energy-saving lighting ensures good and bright illumination of the hob.

• Metal grease filter: ensures an always fresh room climate to feel good before, during and after cooking.

Design

• Wall plate, 60 cm

Operating mode and performance

• Optional exhaust air or recirculation mode

• A standard recirculation set or a Clean Air Plus recirculation set (special accessory) is required for recirculation operation
• Noise min./max. Normal level: 48/69 dB

• Max. fan performance 621 m³/h in exhaust mode according to EN 61591

• When using the separately available Clean Air Plus recirculation set (special accessory), your device achieves the following values ​​in recirculation mode:

• Recirculation level: Max. normal operation: 422m³/h

• Noise values ​​for circulating air: Max. normal level: 74 dB(A) re 1 pW

Environment and safety

• Energy efficiency class: B (on an energy efficiency class scale from A+++ to D)
• Average energy consumption: 46.5 kWh/year*

• Fan efficiency class: A*

• Lighting efficiency class: A*

• Grease filter efficiency class: B*

Comfort

• Pushbutton switch

• Ventilation for 3 power levels

• Even, bright lighting with 2 x 1.5 W LED module

• Illuminance: 99 lux

• Color temperature: 3500 K

• Metal grease filter, dishwasher safe
• 2 extraction areas: front and bottom

• Double-flow high-performance blower

• energy-efficient capacitor motor

Technical information

• For wall mounting above hotplates

• Delivery with backflow flap

• Total connected load: 220 W

• Length of connection cable: 1.3 m with plug

• Exhaust air connection Ø 150 mm (Ø 120 mm included)

• Device dimensions for exhaust air (HxWxD): 635-965 x 600 x 500 mm
• Device dimensions for circulating air (HxWxD): 635-1075 x 600 x 500 mm

• Device dimensions recirculation air with Clean Air Plus recirculation set (HxWxD):

• 703 x 600 x 500mm - mounting on external channel

• 833-1163 x 600 x 500 mm - mounting on inner channel

• “Observe dimensions and installation instructions for this device according to the technical drawing”

Technical data

• Design: wall mounting

• Length of connection cable: 130.0 cm

• Chimney height: 583-912/583-1022 mm

• Device height: 53 mm

• Minimum distance to the electric hob: 550 mm

• Minimum distance to the gas hob: 650 mm

• Net weight: 11.5 kg

• Control: mechanical

• Control of the power levels: 3

• Max. fan output exhaust air: 621 m³/h

• Max. fan output for circulating air: 422 m³/h

• Number of lamps (pcs): 2

• Sound power: 69 dB(A) re 1 pW

• Diameter of the exhaust air connection: 120 / 150 mm

• Grease filter material: washable aluminum
• EAN number: 4242005039586

• Connected load: 220 W

• Fuse: 10 A

• Voltage: 220-240V

• Frequency: 50; 60Hz

• Plug type: Schuko/Gardy with grounding

• Device type: Wall mounting

* According to EU regulation No. 65/2014
