For light soiling. Place approx. 400 ml of water and a little washing-up liquid in the cooking chamber and select the cleaning program. The environmentally friendly cleaning system softens burnt-in residues, making them much easier to wipe off afterwards

• LED lighting: The energy-saving lighting ensures good and bright illumination of the hob.
• Quiet: maximum extraction power, low noise

Design

• Fan module gray metallic

• For prepared cabinets above a hob

  .
• 2 metal grease filters, dishwasher-safe
• slide switch

Exhaust air output:

• According to EN 61591 and EN/IEC 60704-2-13, the device can achieve the following values in exhaust air mode:

  • Performance level 1: fan performance 224 m3/h; Noise value 46 dB(A) re1pW

  • Performance level 2: fan performance 365 m3/h; Noise value 57 dB (A) re1pW

  • Performance level 3: fan performance 460 m3/h; Noise value 63 dB (A) re1pW

• Intensive level 1: fan performance 604 m3/h; Noise value 68 dB (A) re1pW

• Energy efficiency class: D (on an energy efficiency class scale from A+++ to D)

• Average energy consumption: 89.4 kWh/year*

• Fan efficiency class: D*

• Lighting efficiency class: A*

• Grease filter efficiency class: B*

Recirculation air performance:

• A standard activated carbon filter is required for recirculation mode (special accessory) - In accordance with EN 61591 and EN/IEC 60704-2-13, your device can operate in recirculation mode with the standard air recirculation set (available as an optional accessory). reach:

  • Performance level 1: Fan performance 150 m3/h; Noise value 56 dB(A) re1pW

  • Performance level 2: Fan performance 248 m3/h; Noise value 67 dB(A) re1pW

  • Performance level 3: Fan performance 302 m3/h ; Noise value 71 dB(A) re1pW

  • Intensive level 1: fan performance 346 m3/h; Noise value 73 dB (A) re1pW

Environment

• Total connected load: 206 W

• Voltage: 220 - 240 V

• Sustainability:- Made in Germany: manufactured in a CO2-neutral production facility

Information on planning and installation:

• Device dimensions (HxWxD): 215 x 530 x 380 mm

• Installation dimensions (HxWxD): 215 x 500 x 350 mm

• Length of connection cable: 1.3 m with plug

• Pipe diameter: Ø 150 mm

Technical information

• Type: fan module/intermediate/substructure hood

• Length of connection cable: 130.0 cm

• Min. niche dimensions for installation (H x W x D): 215mm x 500.0mm x 350mm

• Minimum distance to the electric hob: 650 mm

• Minimum distance to the gas hob: 650 mm

• Net weight: 7.2 kg

• Control: mechanical

• Number of power levels: 3 fan levels and 1 intensive level

• Fan performance at the highest normal level for exhaust air: 460 m³/h

• Fan performance at intensive circulating air level: 346.0 m³/h

• Fan performance at the highest normal level circulating air: 302 m³/h

• Fan performance at intensive exhaust air level: 604 m³/h

• Max. air volume: 460m³/h

• Number of lamps (pcs): 2

• Sound power: 63 dB(A) re 1pW

• Diameter of the exhaust air connection: 150 mm
• Grease filter material: washable aluminum
• EAN number: 4242005539772
• Connection value: 206 W

• Fuse: 10 A

• Voltage: 220-240V

• Frequency: 50 Hz

• Plug type: Schuko/Gardy with grounding

• Device type: Built-in
