• The water place is THE central place in the kitchen. Not only is washing up done here, but meals are also prepared, waste is disposed of, food is washed and sorted, and utensils and cleaning products are stored. The possibilities for equipping a water area are just as diverse as the requirements of the users. A BLANCO UNIT combines the faucet, sink and waste/organization system into a visually and functionally perfectly coordinated unit - entirely according to customer requirements.
• With the BLANCO Multi Frame, the planning and assembly of the components for the base cabinet is significantly simplified. The individual BLANCO UNIT products are already pre-installed in the Multi Frame. The powder-coated, sturdy steel frame accommodates all parts and skilfully utilizes every centimeter.
• The sturdy steel frame not only accommodates the water treatment unit and a waste system from the BLANCO SELECT II series. The organization shelf and the organization drawer offer additional storage space for cleaning utensils etc. If the body is taller, a second organization drawer can be installed - it's almost impossible to use more space. Don't leave an inch unused.
• With the new, space-optimized BLANCO drain fitting, the wastewater drainage is elegantly relocated to the rear area of ​​the base cabinet. The Multi Frame's flexible installation grid ensures that everything stays in the right place and is easy to assemble. If additional components or sockets are required as part of the individual kitchen planning, these can be installed additionally. Cables and hoses can be securely fixed.

Equipment:

• Body height min. 750 mm

• Number of buckets: 1
• Drawers: 1
• Water treatment unit right

Included in delivery (see Figure 7):

• Installation Frame 60

• BLANCO drink.soda (still, medium sparkling or fully sparkling water at any time)

• BLANCO Orga Shelf 60 P

• BLANCO Flat Drawer 40 P MF suitable for Multi Frame II 60 P drink.soda

• BLANCO SELECT II 40/1 Combi MF

• BLANCO AutoMove MF

• Space-saving siphon

For a complete BLANCO UNIT you need the following items (see accessories at the end of the article):

• recommended sinks: ETAGON 6 SILGRANIT black, InFino stainless steel with drain remote control or ETAGON 6 SILGRANIT, black with individual drain remote control
• BLANCO EVOL-S Pro Soda System fitting brushed stainless steel
• BLANCO EVOL-S Pro Soda System fitting satin gold

• BLANCO EVOL-S Pro Soda System fitting black matt
• All sinks for 60s base cabinets from the Blanco range can be combined for maximum individuality. Please note the dimension between the cabinet base and the lower edge of the drain fitting, as can be seen in detail image 8 under dimension "min. B".
• The sink and tap must be purchased separately and are not included. If these are included in images in the article, they are for illustrative purposes only.

Requirements for assembly:

• Wastewater connection and hot and cold water connections (3/8") are available and correspond to the position in Figure 1 (Figure 8).

• The kitchen is assembled by the assembly date, the sink is installed.
  .
• A 35 mm diameter hole is required to install the fitting in the worktop or kitchen sink.
  .
• The direct use of two sockets (230 V / 16 A) in the base cabinet must be ensured
• The installation location is permanently frost-free and the room temperature is between 16 – 43 °C.
  . Figure 1 (Image 8).
  .
• The base cabinet has additional ventilation slots of at least 75 cm² or sufficiently sized openings to ensure a permanent exchange of air from the base cabinet. If necessary, remove the rear crossbar at the bottom.

• The size of the room in which the Multi Frame is installed is at least 5 m². If the room has a ceiling height lower than 2 m, the room must be larger than 5 m².

• The maximum minimum distance between the fitting and the under-table unit is a maximum of 80 cm.

• The kitchen front of the base cabinet is neither a frame front nor a split front.

• The side walls of the base cabinet have a wall thickness of 16 mm.

• The worktop has a minimum depth of 650 mm.

• The BLANCO Multi Frame II is not compatible with a moisture protection floor.

• Do not place any other components/third-party components in the base cabinet.
• Note: For complete assembly, connection material may be necessary for connecting to the siphon.

Note:

• Please make sure that if you need to change the CO2 cylinder, you use the starter kit item no. Obtain 526138 directly from Blanco in the spare parts shop. This can then always be used again later in the recycling system with item no. 526139 can be replaced. A return slip is always enclosed with the new delivery of the refill cylinders.

• If this is not followed, it is possible that the seals on the device will break and it will then no longer function properly.
• Please note: if the measured water hardness is BELOW 10° dGH, it is no longer guaranteed that the water will bubble up!
• Replacement filters and cartridges, as well as other consumables, can only be purchased directly from the Blanco online shop
