berbel wall box BMK-Z 150 bT, 1090047. 7 YEAR WARRANTY*
*INCLUDING 7 YEARS WARRANTY ( Warranty conditions )
The company berbel is a global company based in Rheine/Westphalia. berbel develops, produces and sells extractor hoods worldwide based on the unique and patented berbel principle. berbel extractor hoods and ventilation systems are developed and produced in Germany. berbel extractor hoods work quietly, efficiently and energy-savingly.
General information about the berbel wall box
The berbel supply air wall box ensures a regulated supply of fresh air in the kitchen interior. It is a functional alternative to the window contact switch.
Special features
Energy-efficient exhaust system thanks to a motor-lockable exhaust pipe With blower door certificate for use in low-energy buildings Can also be used on the weather side of the building No contamination of the outer wall, the exhaust air flow is intelligently directed away High-quality workmanship made entirely of stainless steel Extremely easy to install, even when retrofitting existing exhaust air ducts Please note: this wall box is only suitable for hoods from production period 11/2020. Available variants (these are each created as separate items in our shop):
Wall box BMK-Z 125, suitable for internal pipe diameters of 123 mm Planning information:
When using the BMK-Z with a BMK-L, the reed switch retrofit kit 1002265 is required to connect the devices BMK is motor-operated and requires external power supply - socket within 1 m or extension cable (see accessories recommendation) Please only use pipes with a smooth inner surface/rigid plastic pipes if possible. When using flexible or spiral ducts, performance-reducing (-40%!) airflow turbulence occurs. It is recommended to replace existing flexible/spiral pipes. The standby value of the wall box is approx. 0.3 watts Required core hole: min. 162 mm
Technical information:
Aperture: 265 x 255 mm , approx. 335 mm depth suitable for pipe diameters of 148 mm inside
